EC-582
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P2135 TP SENSOR
7.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control actuator.
2.EC-582, "
Special Repair Requirement"
>> INSPECTION END
8.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001693409
1.CHECK THROTTLE POSITION SENSOR
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Perform EC-582, "
Special Repair Requirement".
4. Turn ignition switch ON.
5. Set shift lever to D (A/T), 1st (M/T) position.
6. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
1. Replace electric throttle control actuator.
2. Go to EC-582, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001693410
1.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-390, "
THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement"
>> GO TO 2.
2.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-390, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement"
>> END
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
F1133
(TP sensor 1 signal)
F11 36 Accelerator pedalFully released More than 0.36V
Fully depressed Less than 4.75V
34
(TP sensor 2 signal)Fully released Less than 4.75V
Fully depressed More than 0.36V

P2138 APP SENSOR
EC-583
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P2138 APP SENSOR
DescriptionINFOID:0000000001693411
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The ECM uses this signal for the engine oper-
ation such as fuel cut.
DTC LogicINFOID:0000000001693412
DTC DETECTION LOGIC
NOTE:
If DTC P2138 is displayed with DTC P1229, first perform the trouble diagnosis for DTC P1229. Refer to
EC-551, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-583, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001693413
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
PBIB1741E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2138Accelerator pedal posi-
tion sensor circuit range/
performanceRationally incorrect voltage is sent to ECM
compared with the signals from APP sensor 1
and APP sensor 2. Harness or connector
(APP sensor 1 and 2 circuit is open or
shorted.)
[Crankshaft position sensor (POS) circuit
is shorted.)
(Refrigerant pressure sensor circuit is
shorted.)
 Accelerator pedal position sensor
(APP sensor 1 and 2)
 Crankshaft position sensor (POS)
 Refrigerant pressure sensor

EC-584
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P2138 APP SENSOR
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
4.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-I
1. Turn ignition switch ON.
2. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 5.
5.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sensor harness connector and ECM harness connector.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO6.
6.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
APP sensor
Ground Voltage
Connector Terminal
E12 (LHD models)
M204 (RHD models)4 Ground Approx. 5V
APP sensor
Ground Voltage
Connector Terminal
E12 (LHD models)
M204 (RHD models)5 Ground Approx. 5V
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)5 E16 102 Existed

P2138 APP SENSOR
EC-585
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
7.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-III
Check harness for short to power and short to ground, between the following terminals.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair short to ground or short to power in harness or connectors.
8.CHECK COMPONENTS
Check the following.
 Crankshaft position sensor (POS) (Refer to EC-519, "
Component Inspection".)
 Refrigerant pressure sensor (Refer to EC-632, "
Diagnosis Procedure".)
Is the inspection result normal?
YES >> GO TO 15.
NO >> Replace malfunctioning component.
9.CHECK APP SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sensor harness connector and ECM harness connector as follows.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair open circuit or short to ground or shot to power in harness or connectors.
10.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
11 .CHECK APP SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between APP sensor harness connector and ECM harness connector as follows.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 13.
NO >> GO TO 12.
ECM Sensor
Connector Terminal Item Connector Terminal
F1174 Refrigerant pressure sensor E17 3
75 CKP sensor (POS) F15 1
E16 102 APP sensorE12 (LHD models)
M204 (RHD models)5
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)2
E16111
Existed
1104
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)3
E1611 0
Existed
6103

EC-586
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P2138 APP SENSOR
12.DETECT MALFUNCTINING PART
 Harness or connectors E7, M69, M25, M201 (RHD models).
 Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or shot to power in harness or connectors.
13.CHECK APP SENSOR
Refer to EC-586, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 15.
NO >> GO TO 14.
14.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-586, "
Special Repair Requirement".
>> INSPECTION END
15.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001693414
1.CHECK ACCELERATOR PEDAL POSITION SENSOR
1. Reconnect all harness connectors disconnected.
2. Turn ignition switch ON.
3. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-586, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001693415
1.PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING
Refer to EC-389, "
ACCELERATOR PEDAL RELEASED POSITION LEARNING : Special Repair Require-
ment".
>> GO TO 2.
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
E1611 0
(APP sensor 1 signal)
E16111
Accelerator pedalFully released 0.6 - 0.9V
Fully depressed 3.9 - 4.7V
103
(APP sensor 2 signal)104Fully released 0.3 - 0.6V
Fully depressed 1.95 - 2.4V

P2138 APP SENSOR
EC-587
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-390, "
THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement".
>> GO TO 3.
3.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-390, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement".
>> END

EC-588
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ASCD BRAKE SWITCH
ASCD BRAKE SWITCH
DescriptionINFOID:0000000001693416
When the brake pedal is depressed, ASCD brake switch is turned OFF and stop lamp switch is turned ON.
ECM detects the state of the brake pedal by this input of two kinds (ON/OFF signal).
Refer to EC-424, "
System Description" for the ASCD function.
Component Function CheckINFOID:0000000001693417
1.CHECK FOR ASCD BRAKE SWITCH FUNCTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DATA MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END.
NO >> Go to EC-588, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001693418
1.CHECK OVERALL FUNCTION-I
Check which type of transmission the vehicle is equipped with.
Is the inspection result normal?
A/T >> GO TO 2.
M/T >> GO TO 6.
2.CHECK ASCD BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ASCD brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Monitor item Condition Indication
BRAKE SW1Brake pedal and/or clutch pedal Slightly depressed OFF
Brake pedal and clutch pedal Fully released ON
ECM
Ground Condition Voltage
Connector Terminal
E16100
(ASCD brake switch signal)GroundBrake pedal and/or clutch pedal Slightly depressed Approx. 0V
Brake pedal and clutch pedal Fully released Battery voltage
ASCD brake switch
Ground Voltage
Connector Terminal
E36 (LHD models)
M205 (RHD models)1 Ground Battery voltage

ASCD BRAKE SWITCH
EC-589
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Check the following.
 Harness connectors M69, E7 (LHD models)
 Harness connectors M25, M201 (RHD models)
 10A fuse (No. 2)
 Harness for open or short between ASCD brake switch and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK ASCD BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ASCD brake switch harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK ASCD BRAKE SWITCH
Refer to EC-591, "
Component Inspection (ASCD Brake Switch)".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace ASCD brake switch.
6.CHECK ASCD CLUCH SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD cluch switch harness connector.
3. Turn ignition switch ON.
4. Check the continuity between ASCD cluch switch harness connector and ground.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 7.
7.CHECK ASCD BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ASCD brake switch harness connector and ground.
Is the inspection result normal?
ASCD brake switch ECM
Continuity
Connector Terminal Connector Terminal
E36 (LHD models)
M205 (RHD models)2 E16 100 Existed
ASCD cluch switch
Ground Condition Voltage (V)
Connector Terminal
E35 (LHD models)
M206 (RHD models)1 Ground Brake pedalSlightly depressed Approx. 0
Fully released Battery voltage
ASCD brake switch
Ground Voltage
Connector Terminal
E36 (LHD models)
M205 (RHD models)1 Ground Battery voltage

EC-590
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ASCD BRAKE SWITCH
YES >> GO TO 9.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART
Check the following.
 Harness connector M69,E7 (LHD models)
 Harness connector M25,M201 (RHD models)
 10A fuse (No. 2)
 Harness for open or short between ASCD brake switch and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
9.CHECK ASCD BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Check the continuity between ASCD brake switch harness connector and ASCD clutch switch harness
connector.
3. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
10.CHECK ASCD BRAKE SWITCH
Refer to EC-591, "
Component Inspection (ASCD Brake Switch)".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace ASCD brake switch.
11 .CHECK ASCD CLUCH SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector
3. Check the continuity between ASCD cluch switch harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
12.CHECK ASCD CLUTCH SWITCH
Refer to EC-591, "
Component Inspection (ASCD Clutch Switch)".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace ASCD clutch switch.
13.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
ASCD brake switch ASCD clutch switch
Continuity
Connector Terminal Connector Terminal
E36 (LHD models)
M205 (RHD models)2E35 (LHD models)
M206 (RHD models)1 Existed
ASCD cluch switch ECM
Continuity
Connector Terminal Connector Terminal
E35 (LHD models)
M206 (RHD models)2 E16 100 Existed

ASCD BRAKE SWITCH
EC-591
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
>> INSPECTION END
Component Inspection (ASCD Brake Switch)INFOID:0000000001693419
1.CHECK ASCD BRAKE SWITCH-I
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Check the continuity between ASCD brake switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK ASCD BRAKE SWITCH-II
1. Adjust ASCD brake switch installation. Refer to BR-6, "
Inspection and Adjustment".
2. Check the continuity between ASCD brake switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ASCD brake switch.
Component Inspection (ASCD Clutch Switch)INFOID:0000000001693420
1.CHECK ASCD CLUTCH SWITCH-I
1. Turn ignition switch OFF.
2. Disconnect ASCD clutch switch harness connector.
3. Check the continuity between ASCD clutch switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK ASCD CLUTCH SWITCH-II
1. Adjust ASCD clutch switch installation. Refer to CL-5, "
On-vehicle Inspection and Adjustment".
2. Check the continuity between ASCD clutch switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ASCD clutch switch.
Terminals Condition Continuity
1 and 2 Brake pedalFully released Existed
Slightly depressed Not existed
Terminals Condition Continuity
1 and 2 Brake pedalFully released Existed
Slightly depressed Not existed
Terminals Condition Continuity
1 and 2 Clutch pedalFully released Existed
Slightly depressed Not existed
Terminals Condition Continuity
1 and 2 Clutch pedalFully released Existed
Slightly depressed Not existed
