NISSAN TIIDA 2007 Service Repair Manual

SHIFT SOLENOID VALVE B
TM-365
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
SHIFT SOLENOID VALVE B
DescriptionINFOID:0000000001713010
Shift solenoid valves A and B are turned ON or OFF by the TCM in response to signals sent from the PNP
switch, vehicle speed and ECM (throttle opening). Gears will then be shifted to the optimum position.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001713011
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001713012
Diagnostic trouble code “SHIFT SOLENOID/V B” with CONSULT-III or 5th judgement flicker without CON-
SULT-III is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.
Possible CauseINFOID:0000000001713013
 Harness or connector
(Solenoid circuit is open or shorted.)
 Shift solenoid valve B
DTC Confirmation ProcedureINFOID:0000000001713014
CAUTION:
 Always drive vehicle at a safe speed.
 If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
2. Touch “START”.
3. Start engine.
4. Drive vehicle in “D” position and allow the transaxle to shift 1 → 2 → 3 (“GEAR”).
5. If the check result is NG, go to TM-365, "
Diagnosis Procedure".
WITHOUT CONSULT-III
1. Start engine.
2. Drive vehicle in D
1→ D2→ D3 position.
3. Perform self-diagnosis.
Refer to TM-38, "
Diagnosis Procedure without CONSULT-III".
4. If the check result is NG, go to TM-365, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001713016
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Start engine.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Read out the value of “SHIFT S/V B” while driving.
Check the value changes according to driving speed.
Gear position 1 2 3 4
Shift solenoid valve A ON (Closed) OFF (Open) OFF (Open) ON (Closed)
Shift solenoid valve B ON (Closed) ON (Closed) OFF (Open) OFF (Open)
Item name Condition Display value
SHIFT S/V BWhen shift solenoid valve B operates.
(When driving in “D
1” or “D2”.)ON
When shift solenoid valve B does not operate.
(When driving in “D
3” or “D4”.)OFF

TM-366
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SHIFT SOLENOID VALVE B
Without CONSULT-III
1. Start engine.
2. Check voltage between TCM connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK SHIFT SOLENOID VALVE B CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
3. CHECK HARNESS BETWEEN TCM AND TERMINAL CORD ASSEMBLY HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly harness connector and TCM connector.
3. Check continuity between terminal cord assembly harness con-
nector terminal and TCM connector terminal.
4. If OK, check harness for short to ground and short to power.
5. If OK, check continuity between ground and transaxle assembly.
6. Reinstall any part removed.
OK or NG
Item name Condition Display value
SHIFT S/V BWhen shift solenoid valve B operates.
(When driving in “D
1” or “D2”.)ON
When shift solenoid valve B does not oper-
ate.
(When driving in “D
3” or “D4”.)OFF
ItemConnec-
torTerminal ConditionJudgement
standard (Ap-
prox.)
Shift sole-
noid valve BE3112 -
GroundWhen shift solenoid
valve B operates.
(When driving in “D
1” or
“D
2”.)Battery volt-
age
When shift solenoid
valve B does not oper-
ate.
(When driving in “D
3” or
“D
4”.)0V
SCIA3253E
Solenoid Valve Connector TerminalResistance (Ap-
prox.)
Shift solenoid valve B E31 12 - Ground 5 - 20 Ω
SCIA3254E
Item Connector Terminal Continuity
TCM E101 12
Ye s
Terminal cord assembly
harness connectorF30 1
SCIA4943E

SHIFT SOLENOID VALVE B
TM-367
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK VALVE RESISTANCE
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly connector in engine room.
3. Check resistance between terminal cord assembly harness con-
nector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5.CHECK DTC
Perform TM-365, "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6.CHECK TCM
1. Check TCM input/output signals. Refer to XX-XX, "*****"
.
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Component InspectionINFOID:0000000001713017
SHIFT SOLENOID VALVE B
 For removal, refer to XX-XX, "*****".
Resistance Check
 Check resistance between terminal and ground.
Operation Check
Solenoid valve Connector Terminal Resistance (Approx.)
Shift solenoid valve B F30 1 - Ground 5 - 20 Ω
SCIA4944E
Solenoid valve TerminalResistance (Ap-
prox.)
Shift solenoid valve B 1 Ground 5 - 20Ω
SCIA2055E

TM-368
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SHIFT SOLENOID VALVE B
 Check solenoid valve by listening for its operating sound while
applying battery voltage to the terminal and ground.
SCIA2058E

OVERRUN CLUTCH SOLENOID VALVE
TM-369
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
OVERRUN CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000001713018
The overrun clutch solenoid valve is activated by the TCM in response to signals sent from the PNP switch,
overdrive control switch, vehicle speed and ECM (throttle opening). The overrun clutch operation will then be
controlled.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001713019
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001713020
Diagnostic trouble code “OVERRUN CLUTCH S/V” with CONSULT-III or 6th judgement flicker without CON-
SULT-III is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.
Possible CauseINFOID:0000000001713021
 Harness or connector
(Solenoid circuit is open or shorted.)
 Overrun clutch solenoid valve
DTC Confirmation ProcedureINFOID:0000000001713022
CAUTION:
 Always drive vehicle at a safe speed.
 If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
2. Touch “START”.
3. Start engine.
4. Accelerate vehicle to a speed of more than 10 km/h (6 MPH) with “D” position (OD ON).
5. Release accelerator pedal completely with “D” position (OD OFF).
6. If the check result is NG, go to TM-369, "
Diagnosis Procedure".
WITHOUT CONSULT-III
1. Start engine.
2. Drive vehicle under the following conditions:
Selector lever position: “D” position (OD ON)
Vehicle speed: Higher than 10 km/h (6 MPH)
3. Perform self-diagnosis. Refer to TM-38, "
Diagnosis Procedure without CONSULT-III".
4. If the check result is NG, go to TM-369, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001713024
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Start engine.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Read out the value of “OVERRUN/C S/V” while driving.
Check the value changes according to driving speed.
Item name Condition Display value
OVERRUN/C S/VWhen overrun clutch solenoid valve operates. (When
overrun clutch disengaged. Refer to XX-XX, "*****"
.)ON
When overrun clutch solenoid valve does not operate.
(When overrun clutch engaged. Refer to XX-XX, "*****"
.)OFF

TM-370
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
OVERRUN CLUTCH SOLENOID VALVE
Without CONSULT-III
1. Start engine.
2. Check voltage between TCM connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK OVERRUN CLUTCH SOLENOID VALVE CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
3. CHECK HARNESS BETWEEN TCM AND TERMINAL CORD ASSEMBLY HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly harness connector and TCM connector.
Item name Condition Display value
OVERRUN/C S/VWhen overrun clutch solenoid valve oper-
ates. (When overrun clutch disengaged. Re-
fer to XX-XX, "*****"
.)ON
When overrun clutch solenoid valve dose
not operate. (When overrun clutch engaged.
Refer to XX-XX, "*****"
.)OFF
ItemConnec-
torTe r m i n a l C o n d i t i o nJudgement
standard (Ap-
prox.)
Overrun
clutch sole-
noid valveE3120 -
GroundWhen overrun clutch so-
lenoid valve operates.
(When overrun clutch
disengaged. Refer to
XX-XX, "*****"
.)Battery volt-
age
When overrun clutch so-
lenoid valve dose not
operate. (When overrun
clutch engaged. Refer
to XX-XX, "*****"
.)0V
SCIA3258E
Solenoid Valve Connector TerminalResistance (Ap-
prox.)
Overrun clutch solenoid
valveE31 20 - Ground 20 - 30 Ω
SCIA3259E

OVERRUN CLUTCH SOLENOID VALVE
TM-371
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Check continuity between terminal cord assembly harness con-
nector terminal and TCM connector terminal.
4. If OK, check harness for short to ground and short to power.
5. If OK, check continuity between ground and transaxle assembly.
6. Reinstall any part removed.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK VALVE RESISTANCE
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly connector in engine room.
3. Check resistance between terminal cord assembly harness con-
nector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5.CHECK DTC
Perform TM-369, "
DTC Confirmation Procedure".
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6.CHECK TCM
1. Check TCM input/output signals. Refer to XX-XX, "*****"
.
2. If NG, recheck TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Component InspectionINFOID:0000000001713025
OVERRUN CLUTCH SOLENOID VALVE
 For removal, refer to XX-XX, "*****".
Resistance Check
Item Connector Terminal Continuity
TCM E101 20
Ye s
Terminal cord assembly
harness connectorF30 3
SCIA3260E
Solenoid valve Connector Terminal Resistance (Approx.)
Overrun clutch solenoid
valveF30 3 - Ground 20 - 30 Ω
SCIA4945E

TM-372
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
OVERRUN CLUTCH SOLENOID VALVE
 Check resistance between terminal and ground.
Operation Check
 Check solenoid valve by listening for its operating sound while
applying battery voltage to the terminal and ground.
Solenoid valve TerminalResistance (Ap-
prox.)
Overrun clutch so-
lenoid valve3 Ground 20 - 30 Ω
SCIA2059E
SCIA2062E

TORQUE CONVERTER CLUTCH SOLENOID VALVE
TM-373
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
TORQUE CONVERTER CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000001713026
 The torque converter clutch solenoid valve is activated, with the gear in D4 and D3, by the TCM in response
to signals sent from the vehicle speed sensor and the ECM (throttle opening). Lock-up piston operation will
then be controlled.
 Lock-up operation, however, is prohibited when A/T fluid temperature is too low.
 When the accelerator pedal is depressed (less than 2/8) on lock-up condition, the engine speed should not
change abruptly. If there is an abrupt change in engine speed, there is no lock-up.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001713027
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000001713028
Diagnostic trouble code “T/C CLUTCH SOL/V” with CONSULT-III or 7th judgement flicker without CONSULT-
III is detected when TCM detects an improper voltage drop while it tries to operate the solenoid valve.
Possible CauseINFOID:0000000001713029
 Torque converter clutch solenoid valve
 Harness or connector
(Solenoid circuit is open or shorted.)
DTC Confirmation ProcedureINFOID:0000000001713030
CAUTION:
 Always drive vehicle at a safe speed.
 If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III and wait at least 1 second.
3. Touch “START”.
4. Start engine and maintain the following conditions for at least 5 consecutive seconds.
VEHICLE SPEED: 80 km/h (50 MPH) or more
THROTTLE POSI: 0.5/8 - 1.0/8
SLCT LVR POSI: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
5. If the check result is NG, go to TM-373, "
Diagnosis Procedure".
WITHOUT CONSULT-III
1. Start engine.
2. Drive vehicle in D
1→ D2→ D3→ D4→ D4 lock-up position.
3. Perform self-diagnosis. Refer to TM-350, "
Diagnosis Procedure without CONSULT-III".
4. If the check result is NG, go to TM-373, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001713032
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Start engine.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
Item name Condition Display value (Approx.)
TCC S/V DUTY Lock-up OFF ⇔ Lock-up ON 4% ⇔ 94%

TM-374
< COMPONENT DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
TORQUE CONVERTER CLUTCH SOLENOID VALVE
3. Read out the value of “TCC S/V DUTY” while driving. Check the value changes according to driving
speed.
Without CONSULT-III
1. Start engine.
2. Check voltage between TCM connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM connector terminal and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
3. CHECK HARNESS BETWEEN TCM AND TERMINAL CORD ASSEMBLY HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect terminal cord assembly harness connector and TCM connector.
3. Check continuity between terminal cord assembly harness con-
nector terminal and TCM connector terminal.
4. If OK, check harness for short to ground and short to power.
5. If OK, check continuity between ground and transaxle assembly.
6. Reinstall any part removed.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
Item name ConditionDisplay value
(Approx.)
TCC S/V
DUTYLock-up OFF ⇔ Lock-up ON 4% ⇔ 94%
ItemConnec-
torTerminal ConditionJudge-
ment stan-
dard
(Approx.)
Torque con-
verter clutch
solenoid
valveE31 3 - GroundWhen A/T performs lock-
up.8 - 15V
When A/T does not per-
form lock-up.0V
SCIA3261E
Solenoid Valve Connector TerminalResistance (Ap-
prox.)
Torque converter clutch
solenoid valveE31 3 - Ground 5 - 20 Ω
SCIA3262E
Item Connector Terminal Continuity
TCM E31 3
Ye s
Terminal cord assembly
harness connectorF30 5
SCIA3263E
