NISSAN TIIDA 2007 Service Repair Manual

ROAD TEST
TM-485
< ON-VEHICLE MAINTENANCE >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Move selector lever to “D”, “2” and “1” positions and check if vehicle
creeps forward.
Does vehicle creep forward in all three positions?
YES >> GO TO TM-485, "Cruise Test - Part 1".
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-144, "
Vehicle Does Not Creep Forward in
"D", "2" or "1" Position".
 Continue “Road Test”.
Cruise Test - Part 1INFOID:0000000001726685
1.CHECK STARTING GEAR (D1) POSITION
1. Drive vehicle for approximately 10 minutes to warm engine oil and ATF up to operating temperature.
2. Park vehicle on flat surface.
3. Push overdrive control switch. (OD OFF indicator lamp is off.)
4. Move selector lever to “P” position.
5. Start engine.
6. Move selector lever to “D” position.
7. Accelerate vehicle by constantly depressing accelerator pedal
half-way.
Read gear position. Refer to XX-XX, "*****"
.
Does vehicle start from D
1?
YES >> GO TO 2.
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-145, "
Vehicle Cannot Be Started from D1".
 Continue “Road Test”.
2.CHECK SHIFT-UP (D1 TO D2)
Check shift-up (D
1 to D2).
Specified speed when shifting from D
1 to D2. Refer to TM-490, "Vehicle Speed When Shifting Gears".
SAT773B
ATF operating temperature: 50 - 80°C (122 - 176°F)
SCIA5472E
SAT775B
SAT495G

TM-486
< ON-VEHICLE MAINTENANCE >[TYPE 2 (4AT: RE4F03B)]
ROAD TEST
Read gear position, throttle opening and vehicle speed.
Refer to XX-XX, "*****"
.
Does A/T shift from D
1 to D2 at the specified speed?
YES >> GO TO 3.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-146, "
A/T Does Not Shift: D1→ D2or Does
Not Kickdown: D4→ D2".
 Continue “Road Test”.
3.CHECK SHIFT-UP (D2 TO D3)
Check shift-up (D
2 to D3).
Specified speed when shifting from D
2 to D3. Refer to TM-490, "Vehicle Speed When Shifting Gears".
Read gear position, throttle opening and vehicle speed.
Refer to XX-XX, "*****"
.
Does A/T shift from D
2 to D3 at the specified speed?
YES >> GO TO 4.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-148, "
A/T Does Not Shift: D2→ D3".
 Continue “Road Test”.
4.CHECK SHIFT-UP (D3 TO D4)
Check shift-up (D
3 to D4).
Specified speed when shifting from D
3 to D4. Refer to TM-490, "Vehicle Speed When Shifting Gears".
Read gear position, throttle opening and vehicle speed.
Refer to XX-XX, "*****"
.
Does A/T shift from D
3 to D4 at the specified speed?
YES >> GO TO 5.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-149, "
A/T Does Not Shift: D3→ D4".
 Continue “Road Test”.
5.CHECK LOCK-UP (D4 TO D4L/U)
Check lock-up (D
4 to D4L/U).
Specified speed when lock-up occurs. Refer to TM-490, "
Vehicle Speed When Performing and Releasing
Complete Lock-up".
Read vehicle speed, throttle opening when lock-up duty
becomes 94%. Refer to XX-XX, "*****"
.
Does A/T perform lock-up at the specified speed?
YES >> GO TO 6.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-151, "
A/T Does Not Perform Lock-up".
 Continue “Road Test”.
6.CHECK LOCK-UP HOLD
Check lock-up hold.
SCIA7188E
SCIA7189E
SCIA7190E
SCIA7191E

ROAD TEST
TM-487
< ON-VEHICLE MAINTENANCE >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
When lock-up duty becomes 94%. Refer to XX-XX, "*****".
Does A/T hold lock-up condition for more than 30 seconds?
YES >> GO TO 7.
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-151, "
A/T Does Not Hold Lock-up Condition".
 Continue “Road Test”.
7.CHECK SHIFT-DOWN (D4L/U TO D4)
Release accelerator pedal.
When lock-up duty becomes 4%. Refer to XX-XX, "*****"
.
Is lock-up released when accelerator pedal is released?
YES >> GO TO 8.
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-152, "
Lock-up Is Not Released".
 Continue “Road Test”.
8.CHECK SHIFT-DOWN (D4 TO D3)
Decelerate vehicle by applying foot brake lightly.
Read gear position and engine speed. Refer to XX-XX,
"*****".
Does engine speed return to idle smoothly when A/T is shifted from
D4 to D3?
YES >> 1. Stop vehicle.
2. Go to TM-487, "
Cruise Test - Part 2".
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-153, "
Engine Speed Does Not Return to
Idle (Light Braking D4→ D3)".
 Continue “Road Test”.
Cruise Test - Part 2INFOID:0000000001726686
1.CHECK STARTING GEAR (D1) POSITION
1. Push overdrive control switch. (OD OFF indicator lamp is off.)
2. Move selector lever to “D” position.
3. Accelerate vehicle by half throttle again.
Read gear position. Refer to XX-XX, "*****"
.
Does vehicle start from D
1?
YES >> GO TO 2.
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-145, "
Vehicle Cannot Be Started from D1".
 Continue “Road Test”.
2.CHECK SHIFT-UP AND SHIFT-DOWN (D3 TO D4 TO D2)
1. Accelerate vehicle to 80 km/h (50 MPH) as shown in the figure.
SAT959I
SAT495G

TM-488
< ON-VEHICLE MAINTENANCE >[TYPE 2 (4AT: RE4F03B)]
ROAD TEST
2. Release accelerator pedal and then quickly depress it fully.
Read gear position and throttle opening. Refer to XX-XX,
"*****".
Does A/T shift from D
4 to D2 as soon as accelerator pedal is
depressed fully?
YES >> GO TO 3.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-146, "
A/T Does Not Shift: D1→ D2or Does
Not Kickdown: D4→ D2".
 Continue “Road Test”.
3.CHECK SHIFT-UP (D2 TO D3)
Check shift-up (D
2 to D3)
Specified speed when shifting from D
2 to D3. Refer to TM-490, "Vehicle Speed When Shifting Gears".
Read gear position, throttle opening and vehicle speed.
Refer to XX-XX, "*****"
.
Does A/T shift from D
2 to D3 at the specified speed?
YES >> GO TO 4.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-148, "
A/T Does Not Shift: D2→ D3".
 Continue “Road Test”.
4.CHECK SHIFT-UP (D3 TO D4) AND ENGINE BRAKE
Release accelerator pedal after shifting from D
2 to D3.
Read gear position, throttle opening and vehicle speed.
Refer to XX-XX, "*****"
.
Does A/T shift from D
3 to D4 and does vehicle decelerate by engine
brake?
YES >> 1. Stop vehicle.
2. Go to TM-488, "
Cruise Test - Part 3".
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-149, "
A/T Does Not Shift: D3→ D4".
 Continue “Road Test”.
Cruise Test - Part 3INFOID:0000000001726687
1.CHECK SHIFT-DOWN (D4 TO D3) (WITH OVERDRIVE CONTROL SWITCH)
1. Push overdrive control switch. (OD OFF indicator lamp is off.)
2. Move selector lever to “D” position.
3. Accelerate vehicle using half throttle to D
4.
SCIA7192E
SAT960I
SAT405H
SAT812A

ROAD TEST
TM-489
< ON-VEHICLE MAINTENANCE >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
4. Release accelerator pedal.
5. Push overdrive control switch. (OD OFF indicator lamp is on.)
Read gear position and vehicle speed. Refer to XX-XX,
"*****".
Does A/T shift from D
4 to D3 (OD OFF)?
YES >> GO TO 2.
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-154, "
A/T Does Not Shift: D4→ D3, When
OD OFF".
 Continue “Road Test”.
2.CHECK ENGINE BRAKE
Check engine brake.
Does vehicle decelerate by engine brake?
YES >> GO TO 3.
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-158, "
Vehicle Does Not Decelerate by
Engine Brake".
 Continue “Road Test”.
3.CHECK SHIFT-DOWN (D3 TO 22)
Move selector lever from “D” to “2” position while driving in D
3 (OD
OFF).
Read gear position. Refer to XX-XX, "*****"
.
Does A/T shift from D
3 (OD OFF) to 22?
YES >> GO TO 4.
NO >>  Mark the box on the XX-XX, "*****"
.
 GO TO TM-155, "
A/T Does Not Shift: D3→ 22, When
Selector Lever "D" → "2" Position" .
 Continue “Road Test”.
4.CHECK ENGINE BRAKE
SAT813A
SCIA5469E
SCIA5469E
SAT791GA

TM-490
< ON-VEHICLE MAINTENANCE >[TYPE 2 (4AT: RE4F03B)]
ROAD TEST
Check engine brake.
Does vehicle decelerate by engine brake?
YES >> GO TO 5.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-158, "
Vehicle Does Not Decelerate by
Engine Brake".
 Continue “Road Test”.
5.CHECK SHIFT-DOWN (22 TO 11)
Move selector lever from “2” to “1” position while driving in 2
2.
Read gear position. Refer to XX-XX, "*****"
.
Does A/T shift from 2
2 to 11 position?
YES >> GO TO 6.
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-156, "
A/T Does Not Shift: 22→ 11, When
Selector Lever "2" → "1" Position" .
 Continue “Road Test”.
6.CHECK ENGINE BRAKE
Check engine brake.
Does vehicle decelerate by engine brake?
YES >> 1. Stop vehicle.
2. Perform self-diagnosis. Refer to XX-XX, "*****"
, XX-
XX, "*****".
NO >>  Mark the box on the XX-XX, "*****"
.
GO TO TM-158, "
Vehicle Does Not Decelerate by
Engine Brake".
 Stop “Road Test”.
Vehicle Speed When Shifting GearsINFOID:0000000001726688
 At half throttle, the accelerator opening is 4/8 of the full opening.
Vehicle Speed When Performing and Releasing Complete Lock-upINFOID:0000000001726689
SAT791GA
SAT778B
SAT778B
Throttle positionVehicle speed [km/h (MPH)]
D1 → D2D2 → D3D3 → D4D4 → D3D3 → D2D2 → D1
Full throttle51 - 59
(32 - 37)97 - 105
(60 - 65) 154 - 162
(96 - 101)150 - 158
(93 - 98)87 - 95
(54 - 59)41 - 49
(25 - 30)
Half throttle31 - 39
(19 - 24)60 - 68
(37 - 42)122 - 130
(76 - 81)63 - 71
(39 - 44)36 - 44
(22 - 27)5 - 13
(3 - 8)
Throttle position Selector lever positionVehicle speed [km/h (MPH)]
Lock-up “ON” Lock-up “OFF”
2.0 / 8D position 76 - 84 (47 - 52) 56 - 64 (35 - 40)
D position (OD OFF) 86 - 94 (53 - 58) 83 - 91 (52 - 57)

TRANSMISSION CONTROL MODULE
TM-491
< ON-VEHICLE REPAIR >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ON-VEHICLE REPAIR
TRANSMISSION CONTROL MODULE
Exploded ViewINFOID:0000000001731415
LHD MODELS
RHD MODELS
Removal and InstallationINFOID:0000000001731416
NOTE:
SCIA6963E
1. TCM
SCIA6092J
1. TCM

TM-492
< ON-VEHICLE REPAIR >[TYPE 2 (4AT: RE4F03B)]
TRANSMISSION CONTROL MODULE
Removal of LHD is shown. TCM for RHD is in the same location and uses the same procedure as LHD. Refer
to TM-30, "
Component Parts Location" for location detail.
REMOVAL
1. Disconnect the battery negative terminal.
2. Disconnect TCM harness connectors (1) from TCM (2).
 Instrument lower finisher (3)
3. Remove TCM (2).
INSTALLATION
Installation is in the reverse order of removal.
SCIA7167E

SHIFT CONTROL SYSTEM
TM-493
< ON-VEHICLE REPAIR >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
SHIFT CONTROL SYSTEM
Control Device Removal and InstallationINFOID:0000000001731421
CONTROL DEVICE COMPONENTS
CONTROL CABLE COMPONENTS
1. Selector lever knob 2. Knob cover 3. Lock pin
4. Overdrive control switch 5. Knob finisher 6. Selector button
7. Selector button return spring 8. Position indicator plate 9. Position lamp
10. Dust cover 11. Bracket 12. Shift lock solenoid and park position
switch assembly
13. A/T device harness connector 14. Plate 15. Control device assembly
WCIA0638E

TM-494
< ON-VEHICLE REPAIR >[TYPE 2 (4AT: RE4F03B)]
SHIFT CONTROL SYSTEM
REMOVAL
CAUTION:
Make sure that parking brake is applied before removal/installation.
1. Place the selector lever in the “N” position.
2. Remove the center console assembly. Refer to IP-11, "
Removal and Installation".
3. Disconnect the A/T device harness connector (1).
4. Remove the key interlock cable from the control device assem-
bly. Refer to TM-499, "
Removal and Installation".
5. Remove the bolts (A) from the control device assembly (1).
6. Remove exhaust front tube, center muffler and heat plates.
Refer to EX-5, "
Removal and Installation".
1. Selector lever knob 2. Control device assembly 3. Lock plate
4. Floor panel 5. Control cable 6. Bracket
7. Lock plate 8. Lock nut 9. A/T assembly
10. Bracket 11. Bracket
WCIA0640E
SCIA6965E
WCIA0609E
