NISSAN TIIDA 2007 Service Repair Manual

TRANSAXLE ASSEMBLY
TM-505
< REMOVAL AND INSTALLATION >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
When installing the torque converter to the transaxle measure dis-
tance A.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
 When replacing an engine or transmission you must make sure any dowels are installed correctly
during re-assembly.
 Improper alignment caused by missing dowels may cause vibration, oil leaks or breakage of drive
train components.
 Do not reuse O-rings and copper washers. Refer to TM-503, "
Exploded View".
 When turning crankshaft, turn it clockwise as viewed from the front of the engine.
 When tightening the bolts for the torque converter while securing the crankshaft pulley bolt, be sure
to confirm the tightening torque of the crankshaft pulley bolt. Refer to EM-50, "
Removal and Installa-
tion".
 After converter is installed to drive plate, rotate crankshaft several turns to check that transaxle
rotates freely without binding.
 When installing the transaxle to the engine, align the matching mark on the drive plate with the matching
mark on the torque converter.
 When securing the transaxle assembly to the engine, attach the
bolts in accordance with the following standard.
(A): A/T to engine
(B): Engine to A/T
 Align the positions for the bolts on drive plate with those of the
torque converter, and temporarily tighten bolts. Then, tighten bolts
to the specified torque.
 After completing installation, check for A/T fluid leakage, A/T fluid
level and A/T positions. Refer to TM-171, "
Checking A/T Fluid" and
TM-497, "
Checking of A/T Position". Dimension A: 16.2 mm (0.638 in) or more
SAT430D
Bolt No. 1234
Number of bolts 2 2 1 3
Bolt length “L”
[mm (in)]40 (1.57) 44 (1.73) 69 (2.72) 49 (1.93)
Tightening torque
[N·m (kg-m, ft-lb)]48 (4.9, 35)
SCIA7096E
Converter bolts : 51 N·m (5.2 kg-m, 38 ft-lb)
WCIA0616E

TM-506
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
OVERHAUL
DISASSEMBLY AND ASSEMBLY
OVERHAUL
ComponentINFOID:0000000001731430
SCIA7177E

OVERHAUL
TM-507
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
1. Pinion mate gear thrust washer 2. Pinion mate gear 3. Pinion mate shaft
4. Lock pin 5. Side gear 6. Side gear thrust washer
7. Differential side bearing 8. Differential case 9. Final gear
10. Differential side bearing adjusting
shim11. Plug 12. O-ring
13. Bracket 14. RH differential side oil seal 15. Torque converter
16. Converter housing 17. Differential lubricant tube 18. Clip
19. O-ring 20. O-ring 21. Oil pump housing oil seal
22. Oil pump housing 23. Outer gear 24. Inner gear
25. Oil pump cover 26. Seal ring 27. Oil pump assembly

TM-508
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
OVERHAUL
1. Retaining plate 2. Driven plate 3. Dish plate
4. Snap ring 5. Spring retainer assembly 6. Reverse clutch piston
7. Seal ring 8. D-ring 9. Reverse clutch drum
10. Thrust washer 11. Reverse clutch assembly 12. Drive plate
13. Snap ring 14. Needle bearing 15. Front sun gear
16. Needle bearing 17. High clutch hub 18. Snap ring
SCIA5893J

OVERHAUL
TM-509
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
19. Retaining plate 20. Drive plate 21. Snap ring
22. Cancel cover 23. Spring retainer assembly 24. High clutch piston
25. Input shaft assembly (high clutch
drum)26. Needle bearing 27. High clutch assembly
28. Bearing race 29. Seal ring 30. Driven plate
31. Needle bearing 32. Needle bearing 33. Overrun clutch hub
34. End bearing 35. Forward clutch hub 36. Needle bearing
37. Rear planetary carrier 38. Rear sun gear 39. Front planetary carrier
40. Low one-way clutch 41. Snap ring 42. Needle bearing
43. Needle bearing 44. Rear internal gear 45. Thrust washer
46. Forward one-way clutch 47. Thrust washer 48. Thrust washer
49. Forward clutch drum 50. Seal ring 51. Seal ring
52. Overrun clutch piston 53. Spring retainer assembly 54. Snap ring
55. Dish plate 56. Driven plate 57. Retaining plate
58. Snap ring 59. Dish plate 60. Driven plate
61. Retaining plate 62. Snap ring 63. Forward clutch assembly and over-
run clutch assembly
64. Drive plate 65. Drive plate 66. D-ring
67. Forward clutch piston 68. D-ring 69. Seal ring
70. Driven plate 71. Snap ring 72. Low & reverse brake assembly
73. Retaining plate 74. Drive plate 75. Retaining plate
76. Dish plate 77. Driven plate 78. Snap ring
79. Spring retainer assembly 80. Low & reverse brake piston 81. D-ring

TM-510
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
OVERHAUL
1. Snap ring 2. Governor cap 3. O-ring
4. Lock nut 5. Anchor end pin 6. Transaxle case
7. Reduction pinion gear bearing 8. Reduction pinion gear 9. Brake band
10. Output shaft 11. Seal ring 12. Output shaft bearing
13. Seal ring 14. Bearing retainer 15. O-ring
16. Servo release accumulator piston 17. Return spring 18. Control valve assembly
SCIA7178E

OVERHAUL
TM-511
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
19. Oil pan gasket 20. Oil pan 21. Drain plug gasket
22. Drain plug 23. Magnet 24. Oil pan fitting bolt
25. Snap ring 26. O-ring 27. O-ring
28. N-D accumulator piston29. Return spring 30. O-ring
31. Lip seal 32. Turbine revolution sensor (power
train revolution sensor)33. O-ring
34. Retaining pin 35. Detent spring 36. Retaining pin
37. Manual shaft 38. Manual shaft oil seal 39. Manual plate
40. Parking rod plate 41. Parking rod 42. OD servo piston retainer
43. Snap ring 44. O-ring 45. OD servo piston
46. D-ring 47. Servo piston retainer 48. O-ring
49. E-ring 50. Spring retainer 51. OD servo return spring
52. D-ring 53. Band servo piston 54. Band servo thrust washer
55. Band servo piston stem 56. 2nd servo return spring 57. PNP switch
58. Parking shaft 59. Return spring 60. Output gear adjusting spacer
61. Output gear bearing 62. Output gear 63. Side cover gasket
64. Side cover 65. Side cover fitting bolt 66. Lock nut
67. Idler gear 68. Idler gear bearing 69. Reduction pinion gear adjusting
shim
70. Parking actuator support 71. Parking pawl 72. LH differential side oil seal
73. Revolution sensor
: Apply locking sealant (Loctite #518).

TM-512
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
OVERHAUL
Oil Channel
INFOID:0000000001731431
SCIA5925E

OVERHAUL
TM-513
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Location of Adjusting Shims, Needle Bearings and Thrust WashersINFOID:0000000001731432
 Refer to TM-320, "Adjusting shims, Needle Bearings, Thrust Washers and Snap Rings".
SCIA6051J

TM-514
< DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)]
OVERHAUL
Location of Snap Rings
INFOID:0000000001731433
 Refer to TM-320, "Adjusting shims, Needle Bearings, Thrust Washers and Snap Rings".
SCIA6170J
