NISSAN TIIDA 2007 Service Repair Manual

DEF-30
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER DOES NOT OPERATE BUT BOTH OF DOOR MIR-
ROR DEFOGGER OPERATE.
REAR WINDOW DEFOGGER DOES NOT OPERATE BUT BOTH OF DOOR
MIRROR DEFOGGER OPERATE.
Diagnosis ProcedureINFOID:0000000001697570
1. CHECK REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT
Check rear window defogger power supply and ground circuit.
Refer to DEF-14, "
Component Function Check".
Is the inspection result normal?
YES >> Refer to XX-XX, "*****".
NO >> Repair or replace the malfunctioning parts.

BOTH DOORS MIRROR DEFOGGER DON’T OPERATE BUT REAR WINDOW
DEFOGGER OPERATES
DEF-31
< SYMPTOM DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
BOTH DOORS MIRROR DEFOGGER DON’T OPERATE BUT REAR WIN-
DOW DEFOGGER OPERATES
Diagnosis ProcedureINFOID:0000000001697571
1. CHECK INTERMITTENT INCIDENT
Check intermittent incident.
Refer to XX-XX, "*****"
.
Is the inspection result normal?
YES >> Check the following.
 Battery power supply circuit.
 Fuse block (J/B).
NO >> Repair or replace the malfunctioning parts.

DEF-32
< SYMPTOM DIAGNOSIS >
DRIVER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
DRIVER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
Diagnosis ProcedureINFOID:0000000001697572
1. CHECK DOOR MIRROR DEFOGGER LH
Check door mirror defogger LH.
Refer to DEF-16, "
Component Function Check".
Is the inspection result normal?
YES >> Refer to XX-XX, "*****".
NO >> Repair or replace the malfunctioning parts.

PASSENGER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
DEF-33
< SYMPTOM DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
PASSENGER SIDE DOOR MIRROR DEFOGGER DOES NOT OPERATE.
Diagnosis ProcedureINFOID:0000000001697573
1. CHECK DOOR MIRROR DEFOGGER RH
Check door mirror defogger RH.
Refer to DEF-18, "
Component Function Check".
Is the inspection result normal?
YES >> Refer to XX-XX, "*****".
NO >> Repair or replace the malfunctioning parts.

DEF-34
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WINDOW
DEFOGGER OPERATES
REAR WINDOW DEFOGGER SWITCH DOES NOT LIGHT, BUT REAR WIN-
DOW DEFOGGER OPERATES
Diagnosis ProcedureINFOID:0000000001697574
1.CHECK CONTROLLER (AUTO AMP.) (REAR WINDOW DEFOGGER SWITCH)
Check that the controller (auto amp.) (rear window defogger switch) is operating normally.
OK or NG
OK >> Refer to XX-XX, "*****".
NG >> Refer to DEF-11, "
Diagnosis Procedure".

PRECAUTIONS
DEF-35
< PRECAUTION >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
PRECAUTION
PRECAUTIONS
Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSION-
ER"
INFOID:0000000001697575
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
 To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SRS section.
 Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.

DEF-36
< ON-VEHICLE REPAIR >
FILAMENT
ON-VEHICLE REPAIR
FILAMENT
Inspection and RepairINFOID:0000000001697576
INSPECTION
1. When measuring voltage, wrap tin foil around the top of the neg-
ative probe. Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of
each filament.
3. If a filament is burned out, circuit tester registers 0 or battery
voltage.
4. To locate burned out point, move probe to left and right along fil-
ament. Test needle will swing abruptly when probe passes the
point.
REPAIR
REPAIR EQUIPMENT
 Conductive silver composition (Dupont No. 4817 or equivalent)
SEL122R
SEL263
SEL265

FILAMENT
DEF-37
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
 Ruler 30 cm (11.8 in) long
 Drawing pen
 Heat gun
 Alcohol
 Cloth
REPAIRING PROCEDURE
1. Wipe broken heat wire and its surrounding area clean with a
cloth dampened in alcohol.
2. Apply a small amount of conductive silver composition to tip of
drawing pen.
Shake silver composition container before use.
3. Place ruler on glass along broken line. Deposit conductive silver
composition on break with drawing pen. Slightly overlap existing
heat wire on both sides [preferably 5 mm (0.20 in)] of the break.
4. After repair has been completed, check repaired wire for conti-
nuity. This check should be conducted 10 minutes after silver
composition is deposited.
Do not touch repaired area while test is being conducted.
5. Apply a constant stream of hot air directly to the repaired area
for approximately 20 minutes with a heat gun. A minimum dis-
tance of 3 cm (1.2 in) should be kept between repaired area and
hot air outlet.
If a heat gun is not available, let the repaired area dry for 24
hours.
SPECIAL REPAIR REQUIREMENT
PIIA0215E
SEL012D
SEL013D

DEF-38
< ON-VEHICLE REPAIR >
CONDENSER
CONDENSER
Exploded ViewINFOID:0000000001697577
Refer to DEF-38, "Exploded View".
Removal and InstallationINFOID:0000000001697578
REMOVAL
1. Remove the rear seat cushion and the rear seat back.
Refer to XX-XX, "*****"
.
2. Remove the rear kickplate, rear wheel well garnish and the rear pillar finisher.
Refer to XX-XX, "*****"
.
3. Remove bolt (A), and then remove condenser (1) from the vehi-
cle body.
INSTALLATION
Install in the reverse order of removal.
JMLIA0013ZZ
