Oil PumpECS004M1
COMPONENTS
DISASSEMBLY
1. Remove seal rings.
2. Loosen bolts in a crisscross pattern and remove oil pump cover.
3. Remove inner and outer gear from oil pump housing.
SCIA0802E
SAT699H
SAT051F
SAT092D

AT-486
[ALL]
REPAIR FOR COMPONENT PARTS
4. Remove O-ring from oil pump housing.
5. Remove oil pump housing oil seal.
INSPECTION
Oil Pump Housing, Oil Pump Cover, Inner Gear and Outer Gear
lCheck for wear or damage.
Side Clearances
lMeasure side clearance of inner and outer gears in at least four
places around each outside edge. Maximum measured values
should be within specified positions.
lIf clearance is less than standard, select inner and outer gear as
a set so that clearance is within specifications.
lIf clearance is more than standard, replace whole oil pump
assembly except oil pump cover.
SAT093D
SAT094D
Standard clearance: 0.030 - 0.050 mm (0.0012 - 0.0020 in)
Inner and outer gear:
Refer toAT- 5 6 3 , "
SERVICE DATA AND SPECIFICA-
TIONS (SDS)"
SAT095D

REPAIR FOR COMPONENT PARTS
AT-487
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
lMeasure clearance between outer gear and oil pump housing.
lIf not within allowable limit, replace whole oil pump assembly
except oil pump cover.
Seal Ring Clearance
lMeasure clearance between seal ring and ring groove.
lIf not within allowable limit, replace oil pump cover assembly.
ASSEMBLY
1. Install oil seal on oil pump housing.
2. Install O-ring on oil pump housing.
lApply ATF to O-ring. Standard clearance: 0.111 - 0.181 mm (0.0044 - 0.0071 in)
Allowable limit: 0.181 mm (0.0071 in)
SAT096D
Standard clearance: 0.1 - 0.25 mm (0.0039 - 0.0098 in)
Allowable limit: 0.25 mm (0.0098 in)
SAT097D
SAT900DA
SAT093D

AT-488
[ALL]
REPAIR FOR COMPONENT PARTS
3. Install inner and outer gears on oil pump housing.
lBe careful of direction of inner gear.
4. Install oil pump cover on oil pump housing.
a. Wrap masking tape around splines of oil pump cover assembly
to protect seal. Position oil pump cover assembly on oil pump
housing assembly, then remove masking tape.
b. Tighten bolts in a crisscross pattern. Tighten oil pump cover
bolts to the specified torque. Refer toAT-489, "
Control Valve
Assembly".
5. Install new seal rings carefully after packing ring groove with
petroleum jelly.
lDo not spread gap of seal ring excessively while install-
ing. The ring may be deformed.
SAT092D
SAT051F
SAT699H

REPAIR FOR COMPONENT PARTS
AT-489
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
Control Valve AssemblyECS004M2
COMPONENTS
1. Oil strainer 2. O-ring 3. Snap ring
4. Terminal body 5. O-rings 6. Control valve lower body
7. Oil cooler relief valve spring 8. Check ball 9. Separating plate
10. Support plate 11. Steel ball 12. Control valve inter body
13. Pilot filter 14. Separating plate 15. Steel ball
16. Control valve upper body 17 Solenoid valve assembly
SCIA0803E

AT-490
[ALL]
REPAIR FOR COMPONENT PARTS
DISASSEMBLY
Disassemble upper, inter and lower bodies.
Bolt length, number and location:
f: Reamer bolt and nut.
1. Remove boltsa,dand nutfand remove oil strainer from con-
trol valve assembly.
2. Remove solenoid valve assembly and line pressure solenoid
valve from control valve assembly.
Bolt symbolabcde f g
Bolt length “ ” mm (in)
13.5
(0.531)58.0
(2.283)40.0
(1.575)66.0
(2.598)33.0
(1.299)78.0
(3.071)18.0
(0.709)
Numberofbolts 63611221
SAT704J
AAT780
SAT062F

REPAIR FOR COMPONENT PARTS
AT-491
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
3. Remove O-rings from solenoid valves and terminal body.
4. Place upper body facedown, and remove boltsb,cand nutf.
5. Remove inter body from lower body.
6. Turn over lower body, and remove accumulator support plate.
7. Remove boltse, separating plate and separating gasket from
lower body.
8. Remove check balls and oil cooler relief valve springs from
lower body.
lBe careful not to lose check balls and oil cooler relief
valve springs.
SCIA0804E
SAT064FA
SAT432D
SAT109D
SAT110DA

AT-492
[ALL]
REPAIR FOR COMPONENT PARTS
9. Remove inter body from upper body.
10. Check to see that steel balls are properly positioned in inter
body and then remove them.
lBe careful not to lose steel balls.
11. Check to see that steel balls are properly positioned in upper
body and then remove them.
lBe careful not to lose steel balls.
INSPECTION
Lower and Upper Bodies
lCheck to see that retainer plates are properly positioned in lower
body.
SAT065F
SAT705J
SAT771J
SAT550G

REPAIR FOR COMPONENT PARTS
AT-493
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
lCheck to see that retainer plates are properly positioned in
upper body.
lBe careful not to lose these parts.
Oil Strainer
lCheck wire netting of oil strainer for damage.
Shift Solenoid Valves “A” and “B”, Line Pressure Solenoid Valve, Torque Converter Clutch
Solenoid Valve and Overrun Clutch Solenoid Valve
lMeasure resistance.
lExcept for EURO-OBD:
lFor shift solenoid valve A, refer toAT-406, "SHIFT SOLENOID
VA LV E A".
lFor shift solenoid valve B, refer toAT- 4 11 , "SHIFT SOLENOID
VA LV E B".
lFor line pressure solenoid valve, refer toAT-436, "LINE PRES-
SURE SOLENOID VALVE".
lFor torque converter clutch solenoid valve, refer toAT-421,
"TORQUE CONVERTER CLUTCH SOLENOID VALVE".
lFor overrun clutch solenoid valve, refer toAT- 4 1 6 , "OVERRUN
CLUTCH SOLENOID VALVE".
lEURO-OBD:
lFor shift solenoid valve A, refer toAT-193, "DTC P0750 SHIFT SOLENOID VALVE A".
lFor shift solenoid valve B, refer toAT-198, "DTC P0755 SHIFT SOLENOID VALVE B".
lFor line pressure solenoid valve, refer toAT-186, "DTC P0745 LINE PRESSURE SOLENOID VALVE".
lFor torque converter clutch solenoid valve, refer toAT-181, "DTC P0740 TORQUE CONVERTER
CLUTCH SOLENOID VALVE".
lFor overrun clutch solenoid valve, refer toAT-208, "DTCP1760OVERRUNCLUTCHSOLENOIDVALVE"
.
Oil Cooler Relief Valve Spring
lCheck springs for damage or deformation.
lMeasure free length and outer diameter.
SAT551G
SCIA0805E
Inspection standard: Refer toAT- 5 6 3 , "SERVICE DATA
AND SPECIFICATIONS (SDS)".
SAT138D

AT-494
[ALL]
REPAIR FOR COMPONENT PARTS
ASSEMBLY
1. Install upper, inter and lower body.
a. Place oil circuit of upper body face up. Install steel balls in their
proper positions.
b. Install upper separating gasket, upper inter separating gasket
and upper separating plate in order shown in illustration.
c. Install reamer boltsffrom bottom of upper body. Using reamer
bolts as guides, install separating plate and gaskets as a set.
d. Install pilot filter.
SAT771J
SAT072F
SAT073FA
SAT074F
