SUBARU FORESTER 2004 Service Repair Manual

LI-17
LIGHTING SYSTEM
Front Turn Signal Light Bulb
13.Front Turn Signal Light Bulb
A: REMOVAL
1) Remove the headlight assembly. REMOVAL, Headlight Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. SPECIFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00021

LI-18
LIGHTING SYSTEM
Clearance Light Bulb
14.Clearance Light Bulb
A: REMOVAL
1) Remove the headlight assembly. REMOVAL, Headlight Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. SPECIFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00022

LI-19
LIGHTING SYSTEM
Front Fog Light Assembly
15.Front Fog Light Assembly
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the two clips and lower mudguard.
3) Disconnect the harness connector.
4) Remove the lower bolts.
5) Remove the mounting bolts and clip, and then
detach the fog light assembly.
B: INSTALLATION
Install in the reverse order of removal.
LI-00023
LI-00024
LI-00025

LI-20
LIGHTING SYSTEM
Front Fog Light Bulb
16.Front Fog Light Bulb
A: REMOVAL
1) Remove the front fog light assembly. 19, REMOVAL, Front Fog Light Assembly.>
2) Remove the back cover.
3) Remove the spring retainer, and then detach the
fog light bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. SPECIFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00026
LI-00027

LI-21
LIGHTING SYSTEM
Rear Combination Light Assembly
17.Rear Combination Light As-
sembly
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the two bolts, and then turn the socket
and disconnect cord assembly to remove rear com-
bination light.
B: INSTALLATION
Install in the reverse order of removal.
LI-00028
LI-00029

LI-22
LIGHTING SYSTEM
Tail/Stop Light Bulb
18.Tail/Stop Light Bulb
A: REMOVAL
1) Remove the rear combination light assembly.
Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00056

LI-23
LIGHTING SYSTEM
Back-up Light Bulb
19.Back-up Light Bulb
A: REMOVAL
1) Remove the rear combination light assembly.
Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00032

LI-24
LIGHTING SYSTEM
Rear Turn Signal Light Bulb
20.Rear Turn Signal Light Bulb
A: REMOVAL
1) Remove the rear combination light assembly.
Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00031

LI-25
LIGHTING SYSTEM
Rear Fog Light Bulb
21.Rear Fog Light Bulb
A: REMOVAL
NOTE:
Rear fog light bulb is attached only to driver’s side
combination light.
1) Remove the rear combination light assembly.
Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00033

LI-26
LIGHTING SYSTEM
License Plate Light
22.License Plate Light
A: REMOVAL
1) Remove the license plate light mounting screw
(A), and then remove the lens.
2) Remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00034(A)
