NISSAN TEANA 2008  Service Manual FRONT WIPER AND WASHER SYSTEM
WW-9
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
Combination switch
(Wiper & washer switch)Refer to BCS-8, "System Diagram".
Combination meter Transmits the ve

Page 5022 of 5121

NISSAN TEANA 2008  Service Manual WW-10
< FUNCTION DIAGNOSIS >
HEADLAMP WASHER SYSTEM
HEADLAMP WASHER SYSTEM
System DiagramINFOID:0000000003771163
System DescriptionINFOID:0000000003771164
OUTLINE
The headlamp washer is controlled by

Page 5023 of 5121

NISSAN TEANA 2008  Service Manual HEADLAMP WASHER SYSTEM
WW-11
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
 IPDM E/R turns ON/OFF the headlamp washer relay by receiving the headlamp washer request signal, and
controls the

Page 5024 of 5121

NISSAN TEANA 2008  Service Manual WW-12
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)INFOID:0000000003941291
APPLICATION ITEM
CONSULT-III perfor

Page 5025 of 5121

NISSAN TEANA 2008  Service Manual DIAGNOSIS SYSTEM (BCM)
WW-13
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
The BCM records the following condition at the moment a particular DTC is detected.
 Vehicle Speed
 Odo/Trip Meter

Page 5026 of 5121

NISSAN TEANA 2008  Service Manual WW-14
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (BCM)
DATA MONITOR
ACTIVE TEST
Monitor Item
[Unit]Description
PUSH SW
[Off/On]The switch status input from push-button ignition switch.
VEH SPEED 1
[km/h]

Page 5027 of 5121

NISSAN TEANA 2008  Service Manual DIAGNOSIS SYSTEM (IPDM E/R)
WW-15
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
DIAGNOSIS SYSTEM (IPDM E/R)
Diagnosis DescriptionINFOID:0000000003941292
AUTO ACTIVE TEST
Description
In auto a

Page 5028 of 5121

NISSAN TEANA 2008  Service Manual WW-16
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (IPDM E/R)
Concept of auto active test
 IPDM E/R starts the auto active test with the door switch signals transmitted by BCM via CAN communica-
tion. The

Page 5029 of 5121

NISSAN TEANA 2008  Service Manual DIAGNOSIS SYSTEM (IPDM E/R)
WW-17
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
CONSULT-III Function (IPDM E/R)INFOID:0000000003941293
APPLICATION ITEM
CONSULT-III performs the following func

Page 5030 of 5121

NISSAN TEANA 2008  Service Manual WW-18
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (IPDM E/R)
ACTIVE TEST
Te s t  i t e m
IGN RLY
[Off/On]×Displays the status of the ignition relay judged by IPDM E/R.
PUSH SW
[Off/On]Displays the status
Trending: gas type, service indicator, battery, fuel cap release, steering, charging, key battery
