NISSAN TIIDA 2007 Service Repair Manual

EXL-90
< ON-VEHICLE REPAIR >
HEADLAMP AIMING CONTROL
INSTALLATION
Installation is in the reverse order of removal.
 Tighten the height sensor bolt closest to the vehicle front first when installing the height sensor.
 The new height sensor must be initialized using Consult III for proper functioning of the automatic headlamp
aiming system.

AUTO LIGHT SYSTEM
EXL-91
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
AUTO LIGHT SYSTEM
Removal and Installation of Light and Rain SensorINFOID:0000000001530408
REMOVAL
1. Remove the rear view mirror. Refer to MIR-9, "Removal and Installation".
2. Disconnect the light and rain sensor connector.
3. Remove the light and rain sensor.
INSTALLATION
Installation is in the reverse order of removal.

EXL-92
< ON-VEHICLE REPAIR >
SIDE TURN SIGNAL LAMP
SIDE TURN SIGNAL LAMP
Bulb ReplacementINFOID:0000000001530538
1. Remove the side turn signal lamp. Refer to EXL-92, "Removal and Installation".
2. Turn bulb socket counterclockwise to unlock it.
3. Remove the bulb from the socket.
Removal and InstallationINFOID:0000000001530539
REMOVAL
1. Insert a suitable tool under the side turn signal lamp. While
pushing in on the side turn signal lamp pawl, pull the lamp away
from the front fender as shown.
2. Disconnect the side turn signal lamp connector and remove the
side turn signal lamp.
NOTE:
Secure the side turn signal lamp harness with tape to prevent
the harness from falling into the front fender.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Install the lamp housing with the bead facing up.
PKIB8657E
PKIB8656E

REAR COMBINATION LAMP
EXL-93
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
REAR COMBINATION LAMP
Bulb ReplacementINFOID:0000000001530525
HATCHBACK
1. Remove the rear combination lamp. Refer to EXL-93, "Removal and Installation".
2. Turn the bulb socket counterclockwise to unlock it.
3. Remove the bulb.
4. Installation is in the reverse order of removal.
SEDAN
1. Remove the trunk side finisher. Refer to INT-35, "Removal and Installation".
2. Turn the bulb socket counterclockwise to unlock it.
3. Remove the stop/tail lamp bulb (1), turn signal lamp bulb (2),
and the back-up lamp bulb (3).
4. Installation is in the reverse order of removal.
Removal and InstallationINFOID:0000000001530526
HATCHBACK
Removal
1. Remove the rear combination lamp nuts.
2. Pull the rear combination lamp toward rear of the vehicle to disengage the pawls.
3. Disconnect the rear combination lamp connector, and remove the rear combination lamp.
Installation
Installation is in the reverse order of removal.
SEDAN
Removal
1. Remove trunk side finisher, if equipped. Refer to INT-35, "Removal and Installation".
2. Disconnect the rear combination lamp connector.
3. Remove the rear combination lamp nuts (1).
4. Remove the rear combination lamp (2).
5. Remove the rear combination lamp seal (3).
Installation
Installation is in the reverse order of removal.
Disassembly and AssemblyINFOID:0000000001530527
Exploded View
PKIC1034E
PKIC1035E

EXL-94
< ON-VEHICLE REPAIR >
REAR COMBINATION LAMP
Hatchback
LKIA0760E
1. Rear combination lamp harness 2. Turn signal lamp bulb 3. Back-up lamp bulb
4. Stop/tail lamp bulb 5. Rear combination lamp housing assembly 6. Bumper stay
A. Grommet B. Nut C. Clip
D. Nuts E. Clip

REAR COMBINATION LAMP
EXL-95
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Sedan
DISSASEMBLY
1. Remove the rear combination lamp harness.
2. Remove the bulbs from the rear combination lamp harness, as necessary.
3. Remove the bumper stay (hatchback only).
4. Remove the rear combination lamp seal (sedan only).
ASSEMBLY
Assembly is in the reverse order of disassembly.
ALLIA0316ZZ
1. Rear combination lamp 2. Back-up lamp bulb 3. Turn signal lamp bulb
4. Stop/tail lamp bulb 5. Rear combination lamp harness

EXL-96
< ON-VEHICLE REPAIR >
HIGH-MOUNTED STOP LAMP
HIGH-MOUNTED STOP LAMP
Bulb ReplacementINFOID:0000000001530528
HATCHBACK
The LED element is not serviced separately, the high-mounted stop lamp must be replaced as an assembly.
SEDAN
1. Open the luggage compartment lid to access the high-mounted stop lamp.
2. Remove the high-mounted stop lamp bulb socket (1) and
remove the high-mounted stop lamp (2).
3. Installation is in the reverse order of removal.
Removal and InstallationINFOID:0000000001530529
HATCHBACK
Removal
1. Remove the rear hatch finish panel. Refer to INT-18, "Removal and Installation".
2. Disconnect the high-mounted stop lamp connector.
3. Remove the high-mounted stop lamp nuts as shown.
4. Remove the high-mounted stop lamp from the rear hatch.
Installation
Installation is in the reverse order of removal.
CAUTION:
Properly seal the high-mounted stop lamp base to the rear hatch to prevent water leaks.
SEDAN
Removal
1. Open the luggage compartment lid to access the high-mounted stop lamp.
PKIC1021E
SKIB7594E

HIGH-MOUNTED STOP LAMP
EXL-97
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
2. Remove the high-mounted stop lamp bulb socket (1) and
remove the high-mounted stop lamp (2).
3. Remove the rear parcel shelf. Refer to INT-26, "
Removal and Installation".
4. Remove the high-mounted stop lamp screws (A) and remove
the high-mounted stop lamp (1).
5. Remove the high-mounted stop lamp finisher screws (A) and
remove the high-mounted stop lamp finisher (1).
Installation
Installation is in the reverse order of removal.
PKIC1021E
PKIC1022E
PKIC1023E

EXL-98
< ON-VEHICLE REPAIR >
LICENSE PLATE LAMP
LICENSE PLATE LAMP
Bulb ReplacementINFOID:0000000001530532
HATCHBACK
1. Remove the license plate lamp. Refer to INT-35, "Removal and Installation".
2. Turn the bulb socket counterclockwise to unlock it.
3. Remove the bulb from the socket.
4. Installation is in the reverse order of removal.
SEDAN
1. Remove the trunk lid finisher. Refer to INT-35, "Removal and Installation".
2. Remove the license plate lamp bulb socket (1) and remove the
license plate lamp bulb (2).
3. Installation is in the reverse order of removal.
Removal and InstallationINFOID:0000000001530533
HATCHBACK
Removal
1. Press the license plate lamp pawl on the side of the rear bumper fascia, then swing the license plate lamp
down to release the license plate lamp hook from the rear bumper fascia.
2. Disconnect the license plate lamp connector and remove the licence plate lamp.
Installation
Installation is in the reverse order of removal.
SEDAN
Removal
PKIC1055E
1. License plate lamp A. Pawl B. Hook
LKIA0759E

LICENSE PLATE LAMP
EXL-99
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
1. Remove the trunk lid finisher. Refer to EXT-29, "Removal and Installation".
2. Remove the license plate lamp bulb socket (1).
 License plate lamp bulb (2).
3. Remove the license plate lamp finisher. Refer to EXT-29, "
Removal and Installation".
4. Remove the license plate lamp assembly.
Installation
Installation is in the reverse order of removal.
PKIC1055E
