CONTROL LINKAGE
TM-675
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Disconnect connectors (A) and then remove bracket (1).
4. While pressing the lock of the select cable in the direction of the
arrow shown, remove the select cable from the selector lever.
5. While pressing the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the shifter lever.
6. While pulling the lock of the select cable in the direction of the
arrow shown, remove the select cable from the cable mounting
bracket.
7. While pulling the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the cable mounting
bracket.
8. Remove the control lever knob.
9. Remove console finisher assembly and the center console
assembly. Refer to IP-11, "
Removal and Installation".
10. Shift the control lever to the neutral position.
11. While pressing the lock of the select cable in the direction of the
arrow shown, remove the select cable from the control device
assembly.
12. While pressing the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the control device
assembly.
13. While pulling the lock of the select cable in the direction of the
arrow shown, remove the select cable from the control device
assembly.
14. While pulling the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the control device
assembly.
15. Remove the control device assembly.
16. Remove the heat plate.
17. Remove the bracket.
JPDIA0240ZZ
JPDIC0066ZZ
JPDIC0067ZZ
JPDIC0066ZZ
JPDIC0067ZZ

TM-676
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
CONTROL LINKAGE
18. Remove the grommet and then remove the shift cable and select cable from the vehicle.
INSTALLATION
Installation is in the reverse order of removal.
 Shift the control lever to the neutral position.
 Securely assemble each cable and the selector lever and shifter lever.
 Securely assemble each cable and the cable mounting bracket.
 Securely assemble each cable and the control device assembly.
 Make sure that the claws of grommet are in contact with the floor.
 Be careful about the installation direction and push the control lever knob into the control lever.
CAUTION:
Never reuse control lever knob.
 Tapping work for tapping bolt is not applied to new clutch housing. Do not perform tapping by other than
screwing tapping bolt because tapping is formed by screwing tapping bolt into clutch housing.
CAUTION:
Never reuse tapping bolt.
Install the select cable (the control device assembly side) with the following procedure.
1. While pulling the lock of the select cable in the direction of the
arrow shown, install the select cable to the control device
assembly.
2. Slide the lock (1) of the select cable in the direction of the arrow
as shown to pull up the stopper (2) of the select cable.
3. Install the end of the select cable to the pin of the control device
assembly.
4. Install the lever stopper pin (1) or a pin [3 mm (0.12 in) dia.] to
the control device assembly.
CAUTION:
Select cable cannot be adjusted accurately without a use of
a lever stopper pin or a pin [3 mm (0.12 in) dia.].
NOTE:
A lever stopper pin is not included in control device assembly.
Therefore, if the control device assembly is not replaced, pre-
pare a pin [3 mm (0.12 in) dia.].
5. Check that the control lever does not move in the direction of the
select. If it moves, repeat step 3.
6. Shift the control lever to 4th gear position.
JPDIC0067ZZ
JPDIC0064ZZ
JPDIC0069ZZ

CONTROL LINKAGE
TM-677
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
7. With the stopper (1) of the select cable pressed into all the way,
slide lock (2) of the select cable all the way in the direction of the
arrow.
8. Remove the lever stopper pin or a pin [3 mm (0.12 in) dia.] from
the control device assembly.
9. Shift the control lever to each gear position to check that there is
no binding. If any, repeat step 3.
InspectionINFOID:0000000001381640
After installing, confirm the following items:
 When the control lever is shifted to 1st-2nd side and 5th-6th side, confirm the control lever returns to neutral
position smoothly.
 When the control lever is shifted to each position, make sure there is no binding or disconnection in each
boot.
JPDIC0065ZZ

TM-678
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
AIR BREATHER HOSE
AIR BREATHER HOSE
Exploded ViewINFOID:0000000001381641
MR18DE ENGINE MODELS
K9K ENGINE MODELS
Removal and InstallationINFOID:0000000001381642
REMOVAL
SCIA7629E
1. Air cleaner case 2. Air breather hose 3. Air duct
4. Clip 5. Transaxle assembly ⇐Two way connector
ALDIA0192ZZ
1. Air duct 2. Transaxle assembly 3. Air breather hose

AIR BREATHER HOSE
TM-679
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P MR18DE Engine Models
1. Remove the battery. Refer to PG-6, "Removal and Installation".
2. Remove air duct and air cleaner case. Refer to EM-269, "
Removal and Installation".
3. Remove the air breather hose.
CAUTION:
When removing air breather hose, be sure to hold two way connector securely.
K9K Engine Models
1. Remove the air duct.
2. Remove the air breather hose.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Make sure air breather hose is not collapsed or blocked due to folding or bending when installed.
MR18DE Engine Models
 When installing air breather hose on two way connector, aim paint mark face toward the vehicle front.
 When installing air breather hose on two way connector, push it until it hits transaxle case.
 When installing air breather hose to air cleaner case, make sure that clips are fully inserted.
K9K Engine Models
 When installing air breather hose to transaxle, aim paint mark face toward the vehicle front.
 When installing air breather hose to transaxle, push it until it hits transaxle case.
 When installing air breather hose to air duct, make sure that clip is fully inserted.

TM-680
< REMOVAL AND INSTALLATION >[6MT: RS6F94R]
TRANSAXLE ASSEMBLY
REMOVAL AND INSTALLATION
TRANSAXLE ASSEMBLY
Exploded ViewINFOID:0000000001381643
MR18DE
SCIA7631E
1. LH engine mount bracket (transaxle
side)2. Transaxle assembly 3. Rear engine mount bracket
4. Washer 5. Rear torque rod⇐Front
: Refer to installation.

TRANSAXLE ASSEMBLY
TM-681
< REMOVAL AND INSTALLATION >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
K9K
Removal and InstallationINFOID:0000000001381644
CAUTION:
If transaxle assembly is removed from the vehicle, always replace CSC (Concentric Slave Cylinder).
Return CSC insert to original position to remove transaxle assembly. Dust on clutch disc sliding parts
may damage seal of CSC and may cause clutch fluid leakage. Refer to CL-11, "
Removal and Installa-
tion".
REMOVAL
1. Drain gear oil. Refer to TM-672, "Draining".
2. Drain clutch fluid and remove clutch tube from CSC. Refer to CL-12, "
Removal and Installation".
CAUTION:
Do not depress clutch pedal during removal procedure.
3. Remove the engine and transaxle as an assembly from the vehicle. Refer to EM-207, "
Removal and
Installation" (MR18DE) or EM-302, "Removal and Installation" (K9K).
4. Remove the transaxle to engine and engine to transaxle bolts.
5. Separate the tranaxle assembly from the engine.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
 The transaxle assembly must not interfere with the wire harnesses and clutch tube.
 When installing transaxle assembly, never bring input shaft into contact with clutch cover.
MR18DE
Tighten bolts to the specified torque.
JPDIC0121GB
1. Transaxle assembly
: Refer to installation.
: Transaxle to engine
: Engine to transaxle
Bolt symbol A B
Quantity 3 6
JPDIC0094ZZ

TM-682
< REMOVAL AND INSTALLATION >[6MT: RS6F94R]
TRANSAXLE ASSEMBLY
K9K
Tighten bolts to the specified torque.
 Refer to CL-11, "
Removal and Installation" for CSC (Concentric Slave Cylinder) installation procedure.
 Refer to TM-674, "
Removal and Installation" for select cable and shift cable installation procedure.
 Bleed the air from the clutch hydraulic system. Refer to CL-8, "
Air Bleeding Procedure".
 After installation, check for oil leakage and oil level. Refer to TM-672, "
Inspection".
“ ” mm (in)60 (2.36) 50 (1.97)
Tightening torque
N·m (kg-m, ft-lb)62.0 (6.3, 46) Bolt symbol A B
: Transaxle to engine
: Engine to transaxle
Bolt symbol A B C
Quantity 2 2 4
“ ” mm (in)50 (1.97) 80 (3.15) 65 (2.56)
Tightening torque
N·m (kg-m, ft-lb)48 (4.9, 35)
JPDIC0054ZZ

TRANSAXLE ASSEMBLY
TM-683
< DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
DISASSEMBLY AND ASSEMBLY
TRANSAXLE ASSEMBLY
Exploded ViewINFOID:0000000001381645
CASE AND HOUSING
1. Filler plug 2. Gasket 3. Transaxle case
4. Bushing 5. Shift finger 6. Snap ring
7. Oil gutter 8. Oil channel 9. Position switch
10. Shifter lever oil seal 11. Shifter lever 12. Retaining pin
13. Bracket 14. Differential side oil seal 15. Selector lever oil seal
16. Selector lever 17. Magnet 18. Drain plug
19. Input shaft oil seal 20. Clutch housing 21. Two way connector
22. Plug (if equipped) 23. Pinion shaft (if equipped) 24. Pinion gear (if equipped)
: Apply Genuine Liquid Gasket, Three Bond 1215 or an equivalent.
JPDIC0071GB

TM-684
< DISASSEMBLY AND ASSEMBLY >[6MT: RS6F94R]
TRANSAXLE ASSEMBLY
SHAFT AND GEAR
1. Input shaft front bearing 2. Input shaft 3. 3rd input gear
4. Washer 5. Snap ring 6. 3rd baulk ring
7. 3rd-4th coupling sleeve 8. 3rd-4th synchronizer hub 9. Insert key
10. 4th baulk ring 11. 4th input gear 12. 5th input gear
13. 5th baulk ring 14. 5th-6th coupling sleeve 15. 5th-6th synchronizer hub
16. 6th baulk ring 17. Needle bearing 18. 6th input gear
19. Input shaft rear bearing
: Apply gear oil.
: Replace the parts as a set.
SFIA3292E
