FUEL SUPPLY
Fuel pressure
13E7J Engine
Shunt terminals (3) and(5) of the fuel pump relay
(L) located in the engine fuse box .
12839S
The pressure must be 3 bars ± 0.2.
By applying a pressure of 500 mbars to the
pressure regulator, a fuel pressure of 2.5 bars ±
0.2 should be obtained.
13-11

FUEL SUPPLY
Antipercolation device
13
When the ignition is switched off, the coolant temperature monitoring mode begins.
E7J Engine
Monitoring mode
Water temperature≥ 101°C
Coolant temperature ≤ 96°C Cooling fan assembly control time
≥ 10 minutes
Cooling fan assembly stops
Exit from monitoring mode
The monitoring mode is left 2 minutes after switching off the ignition in cases where the coolant
temperature is not greater than or equal to 101°C or once the coolant temperature falls below 92°C.
no
yes
nono
yes yes
High speed cooling fan assembly command
13-12

DIESEL EQUIPMENT
General
13
The use of electronic injection in Diesel engines has allowed the operational power of these engines to be
optimised, thus reducing the emission rate of pollutant gases.
The system consists of a computer, which receives information from:
- the coolant temperature sensor,
- the air temperature sensor,
- the engine speed sensor,
- the vehicle speed sensor,
- the load potentiometer,
- the injection start sensor, which forms part of the injector of cylinder n° 3 (injector with sensor).
It controls :
- the injection pump :
• the altimetric corrector (F8Q 630) via a relay
• the advance solenoid valve.
- the cold engine starting system (heater plugs and pre-postheating unit),
- the exhaust gas recycling system (EGR),
- the diesel injection fault warning light,
- the preheating warning light,
- the solenoid valve controlling the fast idle speed LDA,
- the relay controlling the power assisted steering electric pump assembly (for vehicles with air conditio-
ning), the pump assembly is supplied once the engine speed exceeds 650 rpm.
It carries out a self diagnosis procedure which may be visualised through the
XR25.
SPECIAL FEATURES
On the injection pump it is possible to replace:
- the load potentiometer,
- the advance solenoid valve,
- the altimetric corrector,
- the electrical solenoid.
13-13

DIESEL EQUIPMENT
Specifications
13
Vehicles GearboxEngine
Type SuffixBore
(mm)Stroke
(mm)Capacity
(cm
3)RatioCatalytic
converterDepollution
standard
XC0D JB F8Q 662 80 93 1 870 21.5/1 C67 EU96
XC0E JB F8Q 630 80 93 1 870 21.5/1 C67 EU96
Vehicles
ENGINE SPEED (rpm)
Idle speedno load
maximumfull load
maximum
SMOKE OPACITY
Homologation value Legal maximum
XC0D 825 ± 50 4 600 ± 100 4 100 ± 100 1.05 m
-1 (35 %) 2.5 m -1 (64 %)
XC0E 825 ± 50 4 600 ± 100 4 100 ± 100 1.11 m
-1 (36 %) 2.5 m -1 (64 %)
Temperature in °C (± 1°) 0 20 40 80 90
Air temperature sensor
Siemens CTN type
Resistance in Ohms7470 to
119703060 to 4045 1315 to 1600 - -
Coolant temperature sensor
Siemens CTN type
Resistance in Ohms- 3060 to 4045 1315 to 1600 300 to 370 210 to 270
13-14

DIESEL EQUIPMENT
Specifications
13
DESCRIPTIONMAKE/TYPESPECIAL NOTES
Computer LUCAS 25 track (in case of computer replacement,
programme the new computer to memorise the
full load position of the load potentiometer)
Injection - Indirect
Injection pump
LUCAS DIESEL
8448B171 A/231A
(F8Q 630)
8448B152 B/241B
(F8Q 662)Rotary pump fitted with :
- an advance solenoid valve,
- an altimetric corrector (F8Q 630).
Pump setting (obtain TDC
point using ∅ 8 mm pin) - Dimension ( X ) on pump
Injector holders
LUCAS DIESEL
LCR 6735 405Tightening torque: 7 daN.m (injector on injector
holder and injector holder on cylinder head )
Holder for injector with sensor
(needle lift)
LUCAS DIESEL
LDCR020011AA1Tightening torque : 7 daN.m
Resistance ≈ 105 Ω
Injectors
LUCAS DIESEL
RDN OSDC 6902Opening pressure : 130 bars
Maximum pressure difference: 8 bars
EGR solenoid valve
-Voltage: 12 volts
Resistance : 46 ± 5 Ω
Injector pipes
-Ø interior : 2.5 mm
Length: 330 ± 5 mm
Preheating relay housing
-With pre-postheating function (command
controlled by the computer)
Plugs BERU
Pencil type plugResistance : 0.8 Ω
Tightening torque : 2 daN.m
TDC sensor - Resistance : 220 Ω
Fast idle solenoid valve
-Voltage: 12 V
Resistance : 46 Ω
Advance corrector
-Voltage: 12 V
Resistance : 11.5 Ω
Load potentiometer
-Voltage : 5 V
Resistance : (in K Ω, approximately )
Altimetric corrector
-Voltage : 12 V
Resistance : 15.5 Ω
Fault finding Fiche n° 43
Code D34
Selector S8-+5
- 5
Track
(10 track connector)no load full load
5-4
3-4
3-54.5
5.6
2.84.5
2.8
5.6
13-15

DIESEL EQUIPMENT
Location of components
13
1 EGR valve and solenoid valve
2 Air temperature sensor (white connector)
3 Coolant temperature sensor (white connector)
4 Diesel injection computer
5 Fuel filter
6 Pre-postheating plug relay housing
7 TDC sensor
8 Fast idle solenoid valve
9 Electrical solenoid / coded solenoid
10 Digital DPC injection pump
11 Load potentiometer
12 Advance solenoid valve
13 Altimetric corrector
14 Injector with sensor (needle lift)
12874
13-16

DIESEL EQUIPMENT
Location of components
13
12Advance solenoid valve
14Injector with sensor
13Altimetric corrector
11Load potentiometer
9Electrical solenoid / coded solenoid valve
8Idle speed solenoid valve
12869-1R
3Coolant temperature sensor
2Air temperature sensor
6Pre-postheating plug relay housing
5Fuel filter
16Inertia switch
4Injection computer
13083R
12872R
19 EGR solenoid valve
12871R
13-17

DIESEL EQUIPMENT
Location of components
13
20 EGR valve
13047-1R
7Engine speed sensor
13048R
87970R
17Diesel injection fault warning light
18Preheating warning light
Warning light illuminates when ignition is
switched on during preheating phase.
12839S
C Power assisted steering pump assembly relay
HAltimetric corrector relay
LInjection locking relay
MDiesel heating relay
13-18

DIESEL EQUIPMENT
Advance solenoid valve (1)
13
10314-1R
SPECIAL TOOLING REQUIRED
Mot. 997-01 Tool for removing injector and
advance solenoid valve
Advance solenoid valve 3
TIGHTENING TORQUES (in daN.m)
REMOVAL
Disconnect the electrical connector from the
pump.
Remove the two terminal connectors for the ad-
vance solenoid from the 10 track pump connec-
tor.
13-19

DIESEL EQUIPMENT
Advance solenoid valve
13
13342R
To remove the terminals from the pump
connector :
1) Pull the yellow guide to release the terminal
connectors, then press on the two tabs on
each side of the connector.
2) Extract the yellow guide.
3) Pull the wire to be removed.
4) The terminal connector is secured by two
tabs, one on each side ; using a screwdriver,
move one of these to one side (the action of
pulling on the wire prevents the tab from
going back into place).
5) Using a screwdriver, move the other tab to
one side.
The terminal connector can now be removed from
the connector.Remove the protective sheath grouping the pump
actuators.
Remove the protective cover from the solenoid
valve.
Remove the solenoid valve using tool Mot. 997-
01.
10579R1
APassage of connector
