Page 851 of 2000

TOYOTA RAV4 2006  Service Repair Manual 2AZ-FE COOLING  –  RADIATORCO–33
CO
5. INSTALL UPPER RADIATOR SUPPORT BRACKET
(a) Install the bracket with the 2 bolts.
Torque: 19 N*m (194 kgf*cm, 14 ft.*lbf)
6. CONNECT HORN CONNECTOR
(a) Connec

Page 852 of 2000

TOYOTA RAV4 2006  Service Repair Manual CO–342AZ-FE COOLING  –  RADIATOR
CO
(b) Connect the 2 fan motor connectors.
11. INSTALL NO. 1 WATER BY-PASS PIPE
(a) Install the by-pass pipe with the 2 bolts to the upper
radiator support.
Torqu

Page 853 of 2000

TOYOTA RAV4 2006  Service Repair Manual 2AZ-FE COOLING  –  RADIATORCO–35
CO
14. CONNECT HOOD LOCK SWITCH CONNECTOR
15. INSTALL RADIATOR GRILLE SUB-ASSEMBLY (See
page ET-10)
16. INSTALL BATTERY
17. INSTALL BATTERY CLAMP
(a) Attach the h

Page 854 of 2000

TOYOTA RAV4 2006  Service Repair Manual CO–62GR-FE COOLING  –  COOLING FAN SYSTEM
CO
ON-VEHICLE INSPECTION
HINT:
It is normal for the cooling fan to sometimes rotate when the
ignition switch is turned from ACC to ON.
1. CHECK COOLING F

Page 855 of 2000

TOYOTA RAV4 2006  Service Repair Manual 2GR-FE COOLING  –  COOLING FAN SYSTEMCO–7
CO
(c) Check that the cooling fan rotates.
If it does not, check the engine coolant temperature
sensor, cooling fan, harness or connector.
A132415

Page 856 of 2000

TOYOTA RAV4 2006  Service Repair Manual 2GR-FE COOLING  –  WATER PUMPCO–13
CO
6. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY
(a) Remove the bolt, No. 2 idler pulley cover plate and
No. 2 idler pulley.
7. REMOVE V-RIBBED BELT TENSIONER ASSEM

Page 857 of 2000

TOYOTA RAV4 2006  Service Repair Manual CO–142GR-FE COOLING  –  WATER PUMP
CO
NOTICE:
• Be sure to replace the 2 C bolts with new
ones or reuse them after applying adhesive.
Adhesive:
Toyota Genuine Adhesive 1344, Three Bond
1344 or

Page 858 of 2000

TOYOTA RAV4 2006  Service Repair Manual 2GR-FE COOLING  –  WATER PUMPCO–15
CO
(b) Install the water inlet with the 2 bolts and nut.
Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
NOTICE:
Be careful not to allow the O-ring to get caught
between

Page 859 of 2000

TOYOTA RAV4 2006  Service Repair Manual 2GR-FE COOLING  –  THERMOSTATCO–19
CO
REMOVAL
1. REMOVE FRONT WHEEL RH
2. REMOVE NO. 1 ENGINE UNDER COVER (See page
EM-21)
3. REMOVE ENGINE UNDER COVER REAR RH (See
page EM-21)
4. REMOVE FRONT S

Page 860 of 2000

TOYOTA RAV4 2006  Service Repair Manual CO–202GR-FE COOLING  –  THERMOSTAT
CO
14. REMOVE WATER INLET
(a) Remove the 2 nuts and remove the water inlet from
the water inlet housing.
15. REMOVE THERMOSTAT
INSPECTION
1. INSPECT THERMOSTAT
