JAGUAR XFR 2010 1.G Workshop Manual

www.JagDocs.com

Climate Control - Evaporator
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

All vehicles Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Heater Core and Evaporator Core Housing (412-01 Climate Control, Removal and Installation).

3. Refer to: Thermostatic Expansion Valve (412-01 Climate Control, Removal and Installation).

Right-hand drive vehicles

4. CAUTION: Take extra care not to damage the clips or
screw threads. Failure to follow this instruction may result
in damage to the climate control assembly.

Torque: 1.3 Nm











5. Torque: 1.3 Nm

7.
All vehicles


8.







































NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
Torque: 1.3 Nm Left-handdrivevehicles

Installation
9.



































10.

NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.


































WARNING: Only use moderate force when installing
the sensor.
CAUTIONS:


Make sure the evaporator temperature sensor harness
does not become trapped.


Make sure that the sensor is correctly installed.


NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.

1. To install, reverse the removal procedure.

Climate Control - Floor Console Register
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Remove both floor console side trim panels.

Refer to: Floor Console Side Trim Panel (501-12 Instrument Panel and Console, Removal and Installation).

2. www.JagDocs.com

Climate Control - Footwell Vent/Duct Blend Door Actuator
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Climate Control Assembly (412-01 Climate Control, Removal and Installation).




Installation

3. CAUTIONS:


Take extra care not to damage the clips or screw
threads. Failure to follow this instruction may result in
damage to the climate control assembly.


Make sure that the component is correctly located on
the locating dowels.


NOTE: RHD illustration shown, LHD is similar.

Torque: 1.3 Nm
1. To install, reverse the removal procedure.

Climate Control - Heater Core
Removal and Installation

Removal

NOTES:


Removal steps in this procedure may contain installation details.


Some variation in the illustrations may occur, but the essential information is always correct.

All vehicles Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Heater Core and Evaporator Core Housing (412-01 Climate Control, Removal and Installation).

Right-hand drive vehicles

3. CAUTION: Take extra care not to damage the clips or
screw threads. Failure to follow this instruction may result
in damage to the climate control assembly.

Torque: 1.3 Nm











4. Torque: 1.3 Nm
