MITSUBISHI LANCER 2005 Workshop Manual

HEATER CONTROL ASSEMBLY AND A/C SWITCH
HEATER, AIR CONDITIONER AND VENTILATION55-77
HEATER CONTROL ASSEMBLY AND A/C SWITCH
REMOVAL AND INSTALLATIONM1552002400347
AC304650
1 2
3
4
5
AB
Removal steps
>>B<<1. Air mixing door control cable
connection
>>A<<2. Mode selection damper cable
connection
3. Knob4. Centre panel
5. Manual air conditioner control panel
assembly Removal steps (Continued)

HEATER CONTROL ASSEMBLY AND A/C SWITCH
HEATER, AIR CONDITIONER AND VENTILATION55-78
INSTALLATION SERVICE POINT
>>A<< BLOWER VENT CHANGEOVER
DAMPER CABLE
1. Set the heater control assembly’s blower vent
changeover knob to the DEF position.
2. Set the heater unit’s blower vent changeover
damper relay to the DEF position (turn the
damper relay to the left until it stops) and install
the cable.
3. Set the mode locator to the heater unit case and
secure with a clip.
>>B<< AIR MIX DOOR CABLE
CONNECTION
1. Turn the heater control assembly’s temperature
adjustment knob all the way to the HOT side.
2. Set the heater unit’s air mix door lever to the MAX
HOT position (turn the damper lever as the left
illustration) and attach the cable.
3. Set the mode locator to the heater unit case and
secure with a clip.
AC304856DEF position
FACE
position
AB
Mode selection
damper link
Mode locator

AC304854DEF positionFACE position
AB
Mode
selection
damper link

Mode locator
AC304857
MAX HOT
position
MAX. COOL position
AB
Air mix damper leverMode locator

AC304855MAX HOT position
MAX. COOL
position
AB
Air mix damper leverMode locator

HEATER CONTROL ASSEMBLY AND A/C SWITCH
HEATER, AIR CONDITIONER AND VENTILATION55-79
INSPECTIONM1552014300927
BLOWER SWITCH CONTINUITY CHECK
DISASSEMBLY AND REASSEMBLY
M1552014200180
12
6 3
45
AC100615AB
Switch
positionTester connection Specified
condition
0 (OFF) 1 − 2, 2 − 4, 2 − 5, 2 − 6 Open circuit
1 (LO) 1 − 2 Less than 2
ohms
2 (ML) 2 − 4 Less than 2
ohms
3 (MH) 2 − 5 Less than 2
ohms
4 (HI) 2 − 6 Less than 2
ohms
AC100614
1 23
4
5 67 8
AB
Disassembly steps
1. Switch panel
2. Rear window defogger switch
3. Air conditioner switch
4. Inside/outside air selection switch
<>5. Mode selection damper control
cable
<>6. Air mixing damper control cable7. Blower switch assembly
8. Manual air conditioner control panel
(A/C-ECU) Disassembly steps (Continued)

HEATER CONTROL ASSEMBLY AND A/C SWITCH
HEATER, AIR CONDITIONER AND VENTILATION55-80
DISASSEMBLY SERVICE POINT
<> BLOW VENT CHANGEOVER
DAMPER CABLE AND AIR MIX DAMPER
CABLE REMOVALInsert a flat-tipped screwdriver into the clip through
the inside of the control base and prize out the clip
claw to disconnect the cables.
AC100619
AB
Clip
claw
(-) flat-tipped
screwdriver

HEATER UNIT, HEATER CORE, BLOWER ASSEMBLY AND EVAPORATOR UNIT
HEATER, AIR CONDITIONER AND VENTILATION55-81
HEATER UNIT, HEATER CORE, BLOWER ASSEMBLY
AND EVAPORATOR UNIT
REMOVAL AND INSTALLATION
M1552011600457
Pre-removal and Post-installation Operation
•Refrigerant draining and Refilling (Refer to Charging
P.55-70 and Discharging P.55-72).
•Engine coolant Draining and Refilling (Refer to GROUP
14, On vehicles service P.14-22).
•Instrument Panel Removal and Installation (Refer to
GROUP 52A, Instrument Panel P.52A-2).
•Air cleaner cover and air flow sensor assembly Removal
and Installation (Refer to GROUP 15, Air cleaner P.15-3).
•Rear console assembly Removal and Installation (Refer
to GROUP 52A, Rear console assembly P.52A-8).
•Front floor console assembly Removal and Installation
(Refer to GROUP 52A, Front floor console assembly
P.52A-6).
•Front seat assembly Removal and Installation (Refer to
GROUP 52A, Front seat assembly P.52A-24).
AC304861
1
2
3
4 5
6
7
8
N
9
AB
12 ± 2 N·m
6, 7O ring -Pipe coupling
A/C compressor oil:
SUN PAG 56
44 ± 10 N·m
44 ± 10 N·m
Removal steps
1. Front deck crossmember
2. Centre duct
3. Intake duct
•Foot duct (RH), Rear heater duct A
(RH) upper side (Refer to
P.55-101.)4. Blower assembly
5. Heater hose connection
<>6. Flexible suction hose connection
<>7. Liquid pipe B connection
8. O ring
9. Heater unitRemoval steps (Continued)

HEATER UNIT, HEATER CORE, BLOWER ASSEMBLY AND EVAPORATOR UNIT
HEATER, AIR CONDITIONER AND VENTILATION55-82
REMOVAL SERVICE POINT
<> FLEXIBLE SUCTION HOSE AND
LIQUID PIPE B DISCONNECTION
CAUTION
As the compressor oil and receiver are highly
moisture absorbent, use a non-porous material
to plug the hose and nipples.
To prevent the entry of dust or other foreign bodies,
plug the dismantled hose and the nipples of the
expansion valves.
HEATER UNIT
DISASSEMBLY AND REASSEMBLY

M1551005400224
AC304862
1
2
3
4
5
6
7
8
9
10
AB
4, 7O ring -Pipe coupling
A/C compressor oil:
SUN PAG 56
N
Disassembly steps
1. Foot duct (LH)
2. Heater core
3. Expansion valve
4. Joint
5. O ring6. Evaporator cover
7. Evaporator
8. Air thermo sensor clip
9. Air thermo sensor
10. Heater caseDisassembly steps (Continued)

HEATER UNIT, HEATER CORE, BLOWER ASSEMBLY AND EVAPORATOR UNIT
HEATER, AIR CONDITIONER AND VENTILATION55-83
DISASSEMBLY AND ASSEMBLY M1551005400235
AC304863
1
2
3
4
5
N
6
7
8
9
AB
6O ring -Pipe coupling
A/C compressor oil:
SUN PAG 56
Disassembly steps
1. Foot duct (RH)
2. Heater core
3. Expansion valve
4. O ring
5. Evaporator cover6. Evaporator
7. Air thermo sensor clip
8. Air thermo sensor
9. Heater caseDisassembly steps (Continued)

HEATER UNIT, HEATER CORE, BLOWER ASSEMBLY AND EVAPORATOR UNIT
HEATER, AIR CONDITIONER AND VENTILATION55-84
BLOWER ASSEMBLY
DISASSEMBLY AND REASSEMBLYM1551005500179
AC3054131AB
3
4
57
6
12
Disassembly steps
1. Joint duct
2. Resister
3. Outside/inside air selection damper
control motor
4. Hose5. Blower motor
6. Air filter
7. Blower caseDisassembly steps (Continued)

BLOWERMOTOR, RESISTOR AND OUTSIDE/ INSIDE AIR SELECTION DAMPER CONTROL MOTOR
HEATER, AIR CONDITIONER AND VENTILATION55-85
BLOWERMOTOR, RESISTOR AND OUTSIDE/
INSIDE AIR SELECTION DAMPER CONTROL MOTOR
REMOVAL AND INSTALLATION
M1551002800320
AC304885AB
2
31
Blower motor removal step
•Front passenger's side under cover
<>1. Blower motor
Resistor removal step
•Glove box (Refer to GROUP 52A,
Instrument Panel P.52A-2).
•Engine-ECU or
Engine-A/T-ECU (Refer to
GROUP 13A, Engine-ECU and
Engine-A/T-ECU P.13A-401).
2. ResistorOutside/inside air selection
damper control motor removal
step
•Glove box (Refer to GROUP 52A,
Instrument Panel P.52A-2).
•Engine-ECU or
Engine-A/T-ECU (Refer to
GROUP 13A, Engine-ECU and
Engine-A/T-ECU P.13A-401).
3. Outside/inside air selection damper
control motor

BLOWERMOTOR, RESISTOR AND OUTSIDE/ INSIDE AIR SELECTION DAMPER CONTROL MOTOR
HEATER, AIR CONDITIONER AND VENTILATION55-86
REMOVAL SERVICE POINT
<> BLOWER MOTOR REMOVAL
NOTE:
Use of commercially available offset screw driver is
recommended.
INSPECTIONM1551006300275
RESISTER CHECK
Use an ohmmeter to measure the resistance
between the terminals. Check that the measured
value is at the standard value.
Standard value:
BLOWER FAN AND MOTOR CHECK
When battery voltage is applied between the
terminals, check that the motor operates. Also, check
that there is no abnormal noise.
AC304916
12
34
AC304843
Measurement terminal Standard value (Ω)
Between terminals 2 and 4
(LO)2.54
Between terminals 1 and 2
(ML)1.24
Between terminals 2 and 3
(MH)0.6
AC100626AB
