Page 1921 of 2103
B O D Y Electric
(4) the main pivot bolt and washer
driven gear.
BUSHING INSTALLATION
bushing” to balance link (shown orientation).
(2) Install balance link into main pivot complete b racket.
(3) Insert balance link installation screw, then ti ghten the
screw.
.
.
TSB Revision
Page 1922 of 2103
42-98BODY Electric Convertible Top
HEADLINER
REMOVAL AND INSTALLATION
‘3
Removal steps
1. Snaps2. Front headliner attaching strap
3. Center headliner attaching strap
4. Headliner
REMOVAL SERVICE POINTS
FRONT HEADLINER ATTACHING STRAPREMOVAL
From a completely closed position, open the convert ible top
half-way.
HEADLINER REMOVAL
Mark the bows lightly at the end of each retainer, then pry
the retainer from the bow. Remove the headliner.
INSTALLATION SERVICE POINT
HEADLINER INSTALLATION
Hook headliner retainer to back side of bow, then a lign the
end of the retainer with the mark and snap front of retainer
onto bow completely.
Page 1923 of 2103
BODY Convertible’
DRIVE MOTOR
REMOVAL AND INSTALLATION
Post-installation OperationConvertibletop fit adjustment (Refer to 1
20 25
1 4 - 1 8
2
Removal steps
l Quarter trim, lower (Refer to GROUP
Trims.)
l Rear speaker bracket A (Refer to
GROUP 54
Speaker.)
1. Rear speaker bracket
2. Spacer
3. drive motor
NOTE
This illustration shows the right side.
The left side is symmetrical to the right side.
REMOVAL SERVICE
MOTOR
Remove lower bolts with spacers first, then upper b olts.
INSPECTION
(1) Check that the motor runs smoothly when the bat tery
is connected directly to the motor terminals.
(2) Furthermore, check that the motor operates in r everse
when the terminal connections are switched.
Page 1924 of 2103
BODY Electric Convertible
FRONT ROOF WEATHERSTRIP,
R E M O V A L A N D I N S T A L L A T I O N
Removal steps
1. Clip2. Front roof weatherstrip
3. Front pillar weatherstrip holder’
4. Front roof weatherstrip holder
Revision
Page 1925 of 2103
BODY Electric Convertible Top
RAIL WEATHERSTRIP AND TOP
R E M O V A L A N D I N S T A L L A T I O N
Adhesive tape: ATD Part or equivalent
0 0 0 0 4 7 4 8
1. Top cover retainer
rail weatherstrip removalsteps
2. front 3. front
4. center 5. center weatherstrip
6.
rear rail weatherstrip
TSB Revision
Page 1926 of 2103
BODY Electric Convertible Top
BALANCE LINK
REMOVAL AND INSTALLATION
I
Removal steps
Quarter trim, lower(Refer to GROUP Trims.)
1. Front healiner attaching strap
2. Center headliner attaching strap
3. Bushing4. Balance link
NOTE
This illustration shows the left side.
The right side is symmetrical to the
side.
REMOVAL SERVICE POINT
FRONT HEADLINER ATTACHING STRAP
REMOVAL
From a fully closed position, raise the convertible top 102
mm to 153 mm (4 in.
6 in.)
TSB Revision
Page 1927 of 2103
BODY Electric Convertible Top
CONVERTIBLE TOP SWITCH
REMOVAL
42620240012
A N D I N S T A L L A T I O N
NOTE indicates the metal clip position.
Removal steps
1. Stopper 2. Center air outlet assembly3. Convertible top switch
REMOVAL SERVICE POINT
AIR OUTLET ASSEMBLY REMOVAL
Using the pry tool, carefully pry the assembly out of the
INSTALLATION SERVICE POINT
CENTER AIR OUTLET ASSEMBLY
INSTALLATION
(1) Turn the cool air bypass lever of the center ai r outlet
fully downward.
(2) Pull the cool air bypass damper lever on the heater unit
side fully toward you, then attach the cable to the pin
of the
(3) Push the outer cable in the direction of the ar row so
there is no looseness, then secure it with the clip.
TSB Revision
Page 1928 of 2103
BODY Electric Convertible
. .INSPECTION,
Switch position
45
OPEN0 0
CLOSE0 0
CONVERTIBLE TOP BYPASS SWITCH
REMOVAL AND INSTALLATION
Removal steps
1. Convertible top bypass switch
LidREMOVAL SERVICE POINT
TOP BYPASS REMOVAL
(1) Slide the lock knob of the lid in the of the arrow
in the illustration to remove lid.
TSB Revision
Page 1929 of 2103
BODY Electric Convertible Top
(2) Depress lower clips.
(3)While holding lower clip, push the lower front of the switch
past the lower clip 5 mm in.)].
(4) Depress upper clip.
(5) While holding upper clip, jiggle and slide swit ch out.
INSPECTION
Switch positionTerminal No.
123
OFF0A
0
MANUAL
CONVERTIBLE TOP CONTROL MODULE
REMOVAL AND INSTALLATION
Page 1930 of 2103
