NISSAN ALMERA TINO 2001  Service Repair Manual DYNAMIC DAMPER (WHERE FITTED)=NLAX0033
NLAX0033S01
Unit: mm (in)
QG YD SR
LH RH LH RH LH RH
Distance“A”178 - 184
(7.01 - 7.24)375 - 381
(14.76 - 15.00)172 - 178
(6.77 - 7.01)190 -196
(7.48 - 7.72)

Page 232 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual SBR686C
Precautions
PRECAUTIONSNLAX0022+When installing each rubber part, final tightening must be
carried out under unladen condition* with tires on ground.
*: Fuel, radiator coolant and engine oil f

Page 233 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual Noise, Vibration and Harshness (NVH)
Troubleshooting
NLAX0025Refer to“Noise, Vibration and Harshness (NVH) Troubleshooting”,
“FRONT AXLE”, AX-3.
SMA525A
On-vehicle Service
REAR AXLE PARTSNLAX0

Page 234 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual Wheel Hub
COMPONENTSNLAX0028
NAX001
1. Spindle
2. Baffle plate
3. ABS sensor rotor4. Wheel hub bearing
5. Wheel bearing lock nut6. Hub cap
7. ABS sensor
REMOVALNLAX0029CAUTION:
+Before removing the re

Page 235 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual SRA711A
1. Remove brake caliper assembly.
2. Remove wheel bearing lock nut.
3. Remove brake rotor (models with disk brake) or brake drum
(models with drum brakes).
4. Remove wheel hub bearing from spi

Page 236 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual SRA712A
+Install wheel hub bearing.
+Tighten wheel bearing lock nut.
Before tightening, apply oil to threaded portion of rear spindle.
Do not reuse wheel bearing lock nut.
: 187 - 254 N·m (19 - 26 kg

Page 237 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual Service Data and Specifications (SDS)
WHEEL BEARING (REAR)=NLAX0031
Wheel bearing axial end play mm (in) 0.05 (0.0020)
Wheel bearing lock nut tightening torque N·m (kg-m, ft-lb) 187 - 254 (19 - 26, 1

Page 238 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual BRAKE SYSTEM
SECTION
BR
CONTENTS
PRECAUTIONS...............................................................3
Supplemental Restraint System (SRS)″AIR
BAG″and″SEAT BELT PRE-TENSIONER″...........

Page 239 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual CALIPER.................................................................38
ROTOR...................................................................39
Installation .....................................

Page 240 of 3051

NISSAN ALMERA TINO 2001  Service Repair Manual Supplemental Restraint System (SRS)“AIR
BAG”and“SEAT BELT PRE-TENSIONER”
NLBR0081The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER” used along with
a sea
