DUCT AND GRILLE
REAR VENTILATOR GRILLE : Exploded View
INFOID:0000000003894532
REAR VENTILATOR GRILLE : Removal and InstallationINFOID:0000000003894533
REMOVAL
Remove console rear cover (rear ventilator grille). Refer to IP-22, "Exploded View".
INSTALLATION
Installation is basically the reverse order of removal.
REAR VENTILATOR DUCT 1
1. Heater & cooling unit assembly 2. Rear foot duct 1 (left) 3. Rear foot duct 2 (left)
4. Rear foot duct 3 (left) 5. Rear ventilator duct 2 6. Console rear cover (Rear
ventilator grille)
7. Rear foot duct 3 (right) 8. Rear foot duct 2 (right) 9. Rear foot duct 1 (right)
10. Rear ventilator duct 1
JPIIA0935ZZ

DUCT AND GRILLE
VTL-111
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
REAR VENTILATOR DUCT 1 : Exploded ViewINFOID:0000000003894534
REAR VENTILATOR DUCT 1 : Removal and InstallationINFOID:0000000003894535
REMOVAL
1. Remove rear ventilator duct 2. Refer to VTL-112, "REAR VENTILATOR DUCT 2 : Exploded View".
2. Remove mounting clip (A), and then remove rear ventilator duct
1 (1).
INSTALLATION
Installation is basically the reverse order of removal.
REAR VENTILATOR DUCT 2
1. Heater & cooling unit assembly 2. Rear foot duct 1 (left) 3. Rear foot duct 2 (left)
4. Rear foot duct 3 (left) 5. Rear ventilator duct 2 6. Console rear cover (Rear
ventilator grille)
7. Rear foot duct 3 (right) 8. Rear foot duct 2 (right) 9. Rear foot duct 1 (right)
10. Rear ventilator duct 1
JPIIA0935ZZ
JPIIA0936ZZ

VTL-112
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
DUCT AND GRILLE
REAR VENTILATOR DUCT 2 : Exploded View
INFOID:0000000003894536
REAR VENTILATOR DUCT 2 : Removal and InstallationINFOID:0000000003894537
REMOVAL
1. Remove center console assembly. Refer to IP-22, "Exploded View".
2. Remove screws (A), and then remove rear ventilator duct 2 (1).
INSTALLATION
Installation is basically the reverse order of removal.
REAR FOOT DUCT 1
1. Heater & cooling unit assembly 2. Rear foot duct 1 (left) 3. Rear foot duct 2 (left)
4. Rear foot duct 3 (left) 5. Rear ventilator duct 2 6. Console rear cover (Rear
ventilator grille)
7. Rear foot duct 3 (right) 8. Rear foot duct 2 (right) 9. Rear foot duct 1 (right)
10. Rear ventilator duct 1
JPIIA0935ZZ
JPIIA0937ZZ

DUCT AND GRILLE
VTL-113
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
REAR FOOT DUCT 1 : Exploded ViewINFOID:0000000003894542
REAR FOOT DUCT 1 : Removal and InstallationINFOID:0000000003894543
REMOVAL
Driver side
1. Remove instrument lower cover LH. Refer to IP-11, "Exploded View".
2. Remove rear foot duct 1 (left) (1).
Passenger side
1. Remove instrument lower cover RH. Refer to IP-11, "Exploded View".
1. Heater & cooling unit assembly 2. Rear foot duct 1 (left) 3. Rear foot duct 2 (left)
4. Rear foot duct 3 (left) 5. Rear ventilator duct 2 6. Console rear cover (Rear
ventilator grille)
7. Rear foot duct 3 (right) 8. Rear foot duct 2 (right) 9. Rear foot duct 1 (right)
10. Rear ventilator duct 1
JPIIA0935ZZ
JPIIA0938ZZ

VTL-114
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
DUCT AND GRILLE
2. Remove the rear foot duct 1 (right) (1).
INSTALLATION
Installation is basically the reverse order of removal.
REAR FOOT DUCT 2
REAR FOOT DUCT 2 : Exploded ViewINFOID:0000000003894544
REAR FOOT DUCT 2 : Removal and InstallationINFOID:0000000003894545
REMOVAL
Driver side
JPIIA0939ZZ
1. Heater & cooling unit assembly 2. Rear foot duct 1 (left) 3. Rear foot duct 2 (left)
4. Rear foot duct 3 (left) 5. Rear ventilator duct 2 6. Console rear cover (Rear
ventilator grille)
7. Rear foot duct 3 (right) 8. Rear foot duct 2 (right) 9. Rear foot duct 1 (right)
10. Rear ventilator duct 1
JPIIA0935ZZ

DUCT AND GRILLE
VTL-115
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
1. Remove rear foot duct 1 (left). Refer to VTL-113, "REAR FOOT DUCT 1 : Exploded View".
2. Pull up driver side floor carpet. Refer to INT-47, "
Exploded View".
3. Remove mounting clip (A), and then remove rear foot duct 2
(left) (1).
Passenger side
1. Remove the rear foot duct 1 (right). Refer to VTL-113, "REAR FOOT DUCT 1 : Exploded View".
2. Pull up passenger side floor carpet. Refer to INT-47, "
Exploded View".
3. Remove mounting clip (A), and then remove rear foot duct 2
(right) (1).
INSTALLATION
Installation is basically the reverse order of removal.
REAR FOOT DUCT 3
JPIIA0940ZZ
JPIIA0941ZZ

VTL-116
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
DUCT AND GRILLE
REAR FOOT DUCT 3 : Exploded View
INFOID:0000000003894546
REAR FOOT DUCT 3 : Removal and InstallationINFOID:0000000003894547
REMOVAL
Driver side
1. Pull up driver side floor carpet. Refer to INT-47, "Exploded View".
2. Remove mounting clip (A) and harness clip (B), and then
remove rear foot duct 3 (left) (1).
Passenger side
1. Pull up passenger side floor carpet. Refer to INT-47, "Exploded View".
1. Heater & cooling unit assembly 2. Rear foot duct 1 (left) 3. Rear foot duct 2 (left)
4. Rear foot duct 3 (left) 5. Rear ventilator duct 2 6. Console rear cover (Rear
ventilator grille)
7. Rear foot duct 3 (right) 8. Rear foot duct 2 (right) 9. Rear foot duct 1 (right)
10. Rear ventilator duct 1
JPIIA0935ZZ
JPIIA0942ZZ

DUCT AND GRILLE
VTL-117
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
2. Remove mounting clip (A) and harness clip (B), and then
remove rear foot duct 3 (right) (1).
INSTALLATION
Installation is basically the reverse order of removal.
FOOT DUCT
FOOT DUCT : Exploded ViewINFOID:0000000003894548
JPIIA0943ZZ
JPIIA0906GB

VTL-118
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
DUCT AND GRILLE
FOOT DUCT : Removal and Installation
INFOID:0000000003894550
REMOVAL
Driver side
1. Remove instrument driver lower panel. Refer to IP-11, "Exploded View".
2. Remove mounting screws (A), and then remove foot duct (left)
(1).
Passenger side
1. Remove blower unit assembly. Refer to VTL-87, "Exploded View".
2. Remove mounting screws (A) and harness clip, and then
remove foot duct (right) (1).
INSTALLATION
Installation is basically the reverse order of removal.
1. Ventilator seal 2. Defroster seal 3. Distributor upper case
4. Center case 5. Heater & cooling unit case cover 6. Foot duct 1 (right)
7. Foot duct 2 (right) 8. Air mix door motor (passenger side) 9. Evaporator pipe assembly
10. Expansion valve 11. O-ring 12. Evaporator
13. Filter cover 14. Air conditioner filter 15. Case packing
16. Heater & cooling unit case (right) 17. Cooler pipe grommet 18. Grommet
19. Heater pipe grommet 20. Heater pipe support 21. Drain hose
22. Heater & cooling unit case (left) 23. Air mix door motor (driver side) 24. Heater core
25. Heater pipe cover 26. Foot duct 2 (left) 27. Foot duct 1 (left)
28. Aspirator hose 29. Aspirator 30. Mode door motor
31. Main link 32. Rod link 33. Ventilator door link
34. Mode door lever 35. Ventilator door lever 36. Max. cool door link
37. Defroster door link 38. Foot door link 39. Max. cool door lever
40. Foot door lever 41. Defroster door lever 42. Adapter case
43. Distributor lower case 44. Ventilator door 45. Intake sensor
46. Intake sensor bracket 47. Foot door 48. Max. cool door
49. Defroster door 50. Air mix door (Slide door)
Refer to GI-4, "
Components" for symbols in the figure.
JPIIA0944ZZ
JPIIA0945ZZ

IONIZER
VTL-119
< ON-VEHICLE REPAIR >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
IONIZER
WITH INTELLIGENT AIR CONDITIONER SYSTEM
WITH INTELLIGENT AIR CONDITIONER SYSTEM : Exploded ViewINFOID:0000000003894551
WITH INTELLIGENT AIR CONDITIONER SYSTEM : Removal and Installation
INFOID:0000000003894552
REMOVAL
1. Remove ventilator duct. Refer to VTL-106, "VENTILATOR DUCT : Exploded View".
2. Remove mounting clips (A), and then remove ionizer (1).
CAUTION:
Never touch the front surface (ceramic part) of ionizer. It is
the discharge electrode.
INSTALLATION
installation is basically the reverse order of removal.
CAUTION:
If there is dirt, use a clean cloth and clean the discharge electrode (ceramic) of ionizer.
1. Ventilator duct 2. Ionizer 3. Ionizer bracket
JPIIA0946ZZ
JPIIA0947ZZ
