NISSAN TEANA 2008 Service Manual

WCS
WCS-1
DRIVER INFORMATION & MULTIMEDIA
C
DE
F
G H
I
J
K L
M B
SECTION WCS
A
O P
CONTENTS
WARNING CHIME SYSTEM
BASIC INSPECTION ....... .............................3
DIAGNOSIS AND REPAIR WORKFLOW ..... .....3
Work Flow ........................................................... ......3
FUNCTION DIAGNOSIS ...............................5
WARNING CHIME SYSTEM .......................... .....5
WARNING CHIME SYSTEM .......................................5
WARNING CHIME SYSTEM : System Diagram . ......5
WARNING CHIME SYSTEM : System Description
......
5
WARNING CHIME SYSTEM : Component Parts
Location ............................................................... ......
6
WARNING CHIME SYSTEM : Component De-
scription .....................................................................
6
LIGHT REMINDER WARNING CHIME ................. ......6
LIGHT REMINDER WARNING CHIME : System
Diagram .....................................................................
7
LIGHT REMINDER WARNING CHIME : System
Description ................................................................
7
LIGHT REMINDER WARNING CHIME : Compo-
nent Parts Location ...................................................
8
LIGHT REMINDER WARNING CHIME : Compo-
nent Description ........................................................
8
PARKING BRAKE RELEASE WARNING CHIME ......8
PARKING BRAKE RELEASE WARNING CHIME
: System Diagram ......................................................
9
PARKING BRAKE RELEASE WARNING CHIME
: System Description .................................................
9
PARKING BRAKE RELEASE WARNING CHIME
: Component Parts Location ....................................
10
PARKING BRAKE RELEASE WARNING CHIME
: Component Description .........................................
10
DIAGNOSIS SYSTEM (METER) ........................11
Diagnosis Description ......................................... ....11
CONSULT-III Function (METER/M&A) ...................12
DIAGNOSIS SYSTEM (BCM) ...........................16
COMMON ITEM ..................................................... ....16
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) .....................................................
16
BUZZER ................................................................. ....17
BUZZER : CONSULT-III Function (BCM - BUZZ-
ER) ..........................................................................
17
COMPONENT DIAGNOSIS .........................19
POWER SUPPLY AND GROUND CIRCUIT ....19
COMBINATION METER ........................................ ....19
COMBINATION METER : Diagnosis Procedure .....19
BCM (BODY CONTROL MODULE) ...................... ....19
BCM (BODY CONTROL MODULE) : Diagnosis
Procedure ............................................................ ....
19
METER BUZZER CIRCUIT ...............................21
Description ...............................................................21
Component Function Check ....................................21
Diagnosis Procedure ..............................................21
WARNING CHIME SYSTEM .............................22
Wiring Diagram - WARNING CHIME - ....................22
ECU DIAGNOSIS .........................................26
COMBINATION METER ...................................26
Reference Value .................................................. ....26
Wiring Diagram - METER - ......................................32
Fail-Safe ..................................................................39
DTC Index ...............................................................40
BCM (BODY CONTROL MODULE) .................41
Reference Value ......................................................41
Wiring Diagram - BCM - ..........................................64
Fail-safe ...................................................................70
DTC Inspection Priority Chart ...............................72
DTC Index ...............................................................73

WCS-2
SYMPTOM DIAGNOSIS .............................75
THE PARKING BRAKE RELEASE WARNING
CONTINUES SOUNDING, OR DOES NOT
SOUND ..............................................................
75
Description ..............................................................75
Diagnosis Procedure ..............................................75
THE LIGHT REMINDER WARNING DOES
NOT SOUND ......................................................
76
Description ..............................................................76
Diagnosis Procedure ...............................................76
PRECAUTION ............................................77
PRECAUTIONS .................................................77
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................
77

WCS
DIAGNOSIS AND REPAIR WORKFLOW
WCS-3
< BASIC INSPECTION >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
Work FlowINFOID:0000000003838690
OVERALL SEQUENCE
DETAILED FLOW
1.OBTAIN INFORMATION ABOUT SYMPTOM
Interview the customer to obtain as much information as possible about the conditions and environment under
which the malfunction occurred.
>> GO TO 2.
2.CHECK SYMPTOM
• Check the symptom based on the information obtained from the customer.
 Check if any other malfunctions are present.
>> GO TO 3.
3.CHECK CONSULT-III SELF-DIAGNOSIS RESULTS
Connect CONSULT-III and perform self-diagnosis. Refer to WCS-12, "
CONSULT-III Function (METER/M&A)".
JSNIA0456GB

WCS-4
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORKFLOW
Are self-diagnosis results normal?
YES >> GO TO 4.
NO >> GO TO 5.
4.NARROW DOWN MALFUNCTIONING PARTS BY SYMPTOM DIAGNOSIS
Perform symptom diagnosis and narrow down the malfunctioning parts.
>> GO TO 5.
5.REPAIR OR REPLACE MALFUNCTIONING PARTS
Repair or replace malfunctioning parts.
NOTE:
If DTC is displayed, erase DTC after repairing or replacing malfunctioning parts.
>> GO TO 6.
6.FINAL CHECK
Check that the warning buzzer in the combination meter operates normally.
Does it operate normally?
YES >> INSPECTION END
NO >> GO TO 1.

WCS
WARNING CHIME SYSTEM
WCS-5
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
FUNCTION DIAGNOSIS
WARNING CHIME SYSTEM
WARNING CHIME SYSTEM
WARNING CHIME SYSTEM : System DiagramINFOID:0000000003838691
WARNING CHIME SYSTEM : System DescriptionINFOID:0000000003838692
COMBINATION METER
 The buzzer (1) for the warning chime system is integrated in the
combination meter.
 The combination meter sounds the alarm buzzer installed in the
combination meter when receiving the buzzer output signal trans-
mitted from each unit.
BCM
BCM receives signals from various units and transmits a buzzer output signal to the combination meter via
CAN communication if it judges that the warning buzzer should be activated.
BCM warning function list
NOTE:
Parking brake release warning chime is detected by combination meter.
JPNIA1017GB
JPNIA1010ZZ
Warning functions Signal name
Light reminder warning chime Ignition switch signal
 Lighting switch position signal
 Door switch signal (driver side)

WCS-6
< FUNCTION DIAGNOSIS >
WARNING CHIME SYSTEM
WARNING CHIME SYSTEM : Component Parts Location
INFOID:0000000003838693
WARNING CHIME SYSTEM : Component DescriptionINFOID:0000000003838694
LIGHT REMINDER WARNING CHIME
1. Front door switch (driver side) 2. Combination switch
(Lighting switch)3. Parking brake switch
4. BCM 5. Combination meter
A. Behind the combination meter
JPNIA1026ZZ
Unit Description
Combination meter Receives a buzzer output signal from the BCM with CAN communication line and sounds the
buzzer.
 Judges whether the parking brake is released from the vehicle speed signal received from the
ABS actuator and electric unit (control unit) with CAN communication line and the parking
brake switch signal from the parking brake switch, and sounds the buzzer if necessary.
BCMTransmits signals provided by various units to the combination meter with CAN communication
line.
ABS actuator and electric unit
(control unit)Transmits the vehicle speed signal to combination meter with CAN communication line.
Combination switch
(Lighting switch)Transmits the lighting switch position signal to BCM.
Front door switch
(driver side)Transmits the door switch signal to BCM.
Parking brake switch Refer to MWI-52, "
Description".

WCS
WARNING CHIME SYSTEM
WCS-7
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
LIGHT REMINDER WARNING CHIME : System DiagramINFOID:0000000003838695
LIGHT REMINDER WARNING CHIME : System DescriptionINFOID:0000000003838696
DESCRIPTION
With ignition switch in the OFF or ACC position, when the driver door is open or the lighting switch is the 1st or
2nd position, the light warning chime will sound.
 BCM detects ignition switch in the OFF or ACC position, front door switch (driver side) ON, and lighting
switch in 1st or 2nd position. Then the BCM transmits the buzzer output signal (light reminder warning
chime) to combination meter with CAN communication line.
 When combination meter receives buzzer output signal (light reminder warning chime), it sounds the buzzer.
WARNING OPERATION CONDITIONS
If all of the following conditions are fulfilled.
 Ignition switch is in the OFF or ACC
 Lighting switch is in the 1st or 2nd position
 Front door switch (driver side) is ON
WARNING CANCEL CONDITIONS
Warning is canceled if any of the following conditions is fulfilled.
 Lighting switch OFF
 Ignition switch ON
 Front door switch (driver side) is OFF
JPNIA0749GB

WCS-8
< FUNCTION DIAGNOSIS >
WARNING CHIME SYSTEM
LIGHT REMINDER WARNING CHIME : Component Parts Location
INFOID:0000000003900514
LIGHT REMINDER WARNING CHIME : Component DescriptionINFOID:0000000003838698
PARKING BRAKE RELEASE WARNING CHIME
1. Front door switch (driver side) 2. Combination switch
(Lighting switch)3. Parking brake switch
4. BCM 5. Combination meter
A. Behind the combination meter
JPNIA1026ZZ
Unit Description
Combination meter Receives a buzzer output signal from the BCM and sounds the buzzer.
BCMJudges the light warning conditions from the signals provided by various switches and transmits a
buzzer output signal to the combination meter via CAN communication line if necessary.
Combination switch
(Lighting switch)Transmits the lighting switch position signal to BCM.
Front door switch (driver side) Transmits the door switch signal to BCM.

WCS
WARNING CHIME SYSTEM
WCS-9
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PARKING BRAKE RELEASE WARNING CHIME : System DiagramINFOID:0000000003838699
PARKING BRAKE RELEASE WARNING CHIME : System DescriptionINFOID:0000000003838700
DESCRIPTION
Parking brake release warning chime judges the remaining parking brake according to the vehicle speed sig-
nal received from the ABS actuator and electric unit (control unit) via CAN communication and the parking
brake switch signal from parking brake switch to sound the warning buzzer.
WARNING OPERATION CONDITIONS
If all of the following conditions are fulfilled. Vehicle speed is 7 km/h (4.3 MPH) or higher
 Parking brake switch ON
WARNING CANCEL CONDITIONS
Warning is canceled if any of the following conditions are fulfilled.
 Vehicle speed is approximately 3 km/h (1.9 MPH) or less
 Parking brake switch OFF
JPNIA0751GB

WCS-10
< FUNCTION DIAGNOSIS >
WARNING CHIME SYSTEM
PARKING BRAKE RELEASE WARNING CHIME : Component Parts Location
INFOID:0000000003900515
PARKING BRAKE RELEASE WARNING CHIME : Component DescriptionINFOID:0000000003838702
1. Front door switch (driver side) 2. Combination switch
(Lighting switch)3. Parking brake switch
4. BCM 5. Combination meter
A. Behind the combination meter
JPNIA1026ZZ
Unit Description
Combination meterJudges the remaining parking brake according to the vehicle speed signal received from the ABS
actuator and electric unit (control unit) via CAN communication and the parking brake switch signal
from parking brake switch and sounds the warning buzzer.
ABS actuator and electric unit
(control unit)Transmits the vehicle speed signal to the combination meter via CAN communication.
Parking brake switch Transmits the parking brake switch signal to the combination meter.
