NISSAN TIIDA 2007 Service Repair Manual

EC-1032
< PRECAUTION >[MR18DE]
PRECAUTIONS
When measuring ECM signals with a circuit tester, never allow
the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.
Do not use ECM ground terminals when measuring input/out-
put voltage. Doing so may result in damage to the ECM’s tran-
sistor. Use a ground other than ECM terminals, such as the
ground.
Do not operate fuel pump when there is no fuel in lines.
Tighten fuel hose clamps to the specified torque.
Do not depress accelerator pedal when starting.
Immediately after starting, do not rev up engine unnecessar-
ily.
Do not rev up engine just prior to shutdown.
When installing C.B. ham radio or a mobile phone, be sure to
observe the following as it may adversely affect electronic
control systems depending on installation location.
-Keep the antenna as far as possible from the electronic con-
trol units.
-Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
-Adjust the antenna and feeder line so that the standing-wave
ratio can be kept smaller.
-Be sure to ground the radio to vehicle body.
SEF348N
SEF709Y
SEF708Y

PREPARATION
EC-1033
< PREPARATION >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000001162003
Commercial Service ToolsINFOID:0000000001162004
Tool number
Tool nameDescription
KV10117100
Heated oxygen sensor
wrenchLoosening or tightening heated oxygen sensor
with 22 mm (0.87 in) hexagon nut
KV10114400
Heated oxygen sensor
wrenchLoosening or tightening heated oxygen sensor 2
a: 22 mm (0.87 in)
KV10118400
Fuel tube adapterMeasuring fuel pressure
S-NT379
S-NT636
PBIB3043E
Tool name Description
Quick connector re-
leaseRemoving fuel tube quick connectors in engine
room
(Available in SEC. 164 of PARTS CATALOG: Par
No. 16441 6N210)
Socket wrench Removing and installing engine coolant tempera-
ture sensor
PBIC0198E
S-NT705

EC-1034
< PREPARATION >[MR18DE]
PREPARATION
Oxygen sensor thread
cleanerReconditioning the exhaust system threads before
installing a new oxygen sensor. Use with anti-
seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for Zirco-
nia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for Tita-
nia Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL specifica-
tion MIL-A-907)Lubricating oxygen sensor thread cleaning tool
when reconditioning exhaust system threads. Tool name Description
AEM488
S-NT779

FUEL PRESSURE
EC-1035
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ON-VEHICLE REPAIR
FUEL PRESSURE
InspectionINFOID:0000000001162005
FUEL PRESSURE RELEASE
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “FUEL PRESSURE RELEASE” in “WORK SUPPORT” mode with CONSULT-III.
3. Start engine.
4. After engine stalls, crank it two or three times to release all fuel pressure.
5. Turn ignition switch OFF.
With CONSULT-III
1. Remove fuel pump fuse located in IPDM E/R.
2. Start engine.
3. After engine stalls, crank it two or three times to release all fuel pressure.
4. Turn ignition switch OFF.
5. Reinstall fuel pump fuse after servicing fuel system.
FUEL PRESSURE CHECK
CAUTION:
 Before disconnecting fuel line, release fuel pressure from fuel line to eliminate danger.
 The fuel hose connection method used when taking fuel pressure check must not be used for other
purposes.
 Be careful not to scratch or put debris around connection area when servicing, so that the quick
connector maintains sealability with O-rings inside.
 Do not perform fuel pressure check with electrical systems operating (i.e. lights, rear defogger, A/C,
etc.) Fuel pressure gauge may indicate false readings due to varying engine load and changes in
manifold vacuum.
NOTE:
Prepare pans or saucers under the disconnected fuel line because the fuel may spill out. The fuel pres-
sure cannot be completely released because C11 models do not have fuel return system.
1. Release fuel pressure to zero.
2. Prepare fuel hose for fuel pressure check B and fuel tube
adapter (KV10118400) D, then connect fuel pressure gauge A.
 : To quick connector
 : To fuel tube (engine side)
 C: Clamp
 Use suitable fuel hose for fuel pressure check (genuine NIS-
SAN fuel hose without quick connector).
 To avoid unnecessary force or tension to hose, use moder-
ately long fuel hose for fuel pressure check.
 Do not use the fuel hose for checking fuel pressure with dam-
age or cracks on it.
 Use Pressure Gauge to check fuel pressure.
3. Remove fuel hose.
 Do not twist or kink fuel hose because it is plastic hose.
PBIB2982E

EC-1036
< ON-VEHICLE REPAIR >[MR18DE]
FUEL PRESSURE
4. Connect fuel hose for fuel pressure check (1) to fuel tube
(engine side) with clamp (2) as shown in the figure.
 No.2 spool (5)
 Wipe off oil or dirt from hose insertion part using cloth moist-
ened with gasoline.
 Apply proper amount of gasoline between top of the fuel tube
(3) and No.1 spool (4).
 Insert fuel hose for fuel pressure check until it touches the
No.1 spool on fuel tube.
 Use NISSAN genuine hose clamp (part number: 16439 N4710
or 16439 40U00).
 When reconnecting fuel line, always use new clamps.
 Use a torque driver to tighten clamps.
 Install hose clamp to the position within 1 - 2 mm (0.04 - 0.08 in).
 Make sure that clamp screw does not contact adjacent parts.
5. Connect fuel tube adapter to quick connector.
 A: Fuel pressure gauge
 B: Fuel hose for fuel pressure check
6. After connecting fuel hose for fuel pressure check, pull the hose
with a force of approximately 98 N (10 kg, 22 lb) to confirm fuel
tube does not come off.
7. Turn ignition switch ON and check for fuel leakage.
8. Start engine and check for fuel leakage.
9. Read the indication of fuel pressure gauge.
 Do not perform fuel pressure check with system operating.
Fuel pressure gauge may indicate false readings.
 During fuel pressure check, confirm for fuel leakage from fuel connection every 3 minutes.
10. If result is unsatisfactory, go to next step.
11. Check the following.
 Fuel hoses and fuel tubes for clogging
 Fuel filter for clogging
 Fuel pump
 Fuel pressure regulator for clogging
If OK, replace fuel pressure regulator.
If NG, repair or replace.Tightening torque: 1 - 1.5 N·m (0.1 - 0.15 kg-m, 9 - 13 in-lb)
At idling:
Approximately 350 kPa (3.5 bar, 3.57 kg/cm
2, 51 psi)
PBIB2983E
PBIB2984E

EVAPORATIVE EMISSION SYSTEM
EC-1037
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
EVAPORATIVE EMISSION SYSTEM
InspectionINFOID:0000000001162006
1. Visually inspect EVAP vapor lines for improper attachment and for cracks, damage, loose connections,
chafing and deterioration.
2. Check EVAP canister as follows:
a. Block port (B). Orally blow air through port (A).
Check that air flows freely through port (C).
b. Block port (A). Orally blow air through port (B).
Check that air flows freely through port (C).
3. Visually inspect the fuel check valve for cracks, damage, loose connections chafing and deterioration.
4. Check fuel check valve as follows:
a. Blow air through connector on the fuel tank side. A considerable
resistance should be felt and a portion of air flow should be
directed toward the EVAP canister side.
b. Blow air through connector on EVAP canister side. Air flow
should be smoothly directed toward fuel tank side.
c. If fuel check valve is suspected or not properly functioning in
step 1 and 2 above, replace it.
5. Inspect fuel tank filler cap vacuum relief valve for clogging, stick-
ing, etc.
a. Wipe clean valve housing.
b. Check valve opening pressure and vacuum.
c. If out of specification, replace fuel filler cap as an assembly.
PBIB0663E
SEF552Y
SEF989X
Pressure:15.3 - 20.0 kPa (0.153 - 0.200 bar, 0.156 - 0.204 kg/
cm2, 2.22 - 2.90 psi)
Va c u u m :–6.0 to –3.4 kPa (–0.06 bar to –-0.034bar, –0.061 to –
0.035 kg/cm
2, –0.87 to –0.49 psi)
SEF943S

EC-1038
< SERVICE DATA AND SPECIFICATIONS (SDS) [MR18DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Idle SpeedINFOID:0000000001162007
*: Under the following conditions
 A/C switch: OFF
 Electric load: OFF (Lights, heater fan & rear window defogger)
 Steering wheel: Kept in straight-ahead position
Ignition TimingINFOID:0000000001162008
*: Under the following conditions
 A/C switch: OFF
 Electric load: OFF (Lights, heater fan & rear window defogger)
 Steering wheel: Kept in straight-ahead position
Calculated Load ValueINFOID:0000000001162009
Mass Air Flow SensorINFOID:0000000001162010
*: Engine is warmed up to normal operating temperature and running under no load.Condition Specification
No load* (in Neutral position) 700 ± 50 rpm
Condition Specification
No load* (in Neutral position) 15 ± 5° BTDC
Condition Specification (Using CONSULT-III or GST)
At idle10 – 35 %
At 2,500 rpm10 – 35 %
Supply voltageBattery voltage (11 – 14 V)
Output voltage at idle0.8 – 1.1V*
Mass air flow (Using CONSULT-III or GST)1.0 – 4.0 g·m/sec at idle*
2.0 – 10.0 g·m/sec at 2,500 rpm*

DIAGNOSIS AND REPAIR WORKFLOW
EC-1039
< BASIC INSPECTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
Work FlowINFOID:0000000001162512
OVERALL SEQUENCE
Diagnostics Malfunctions
JMBIA0634GB

EC-1040
< BASIC INSPECTION >[K9K]
DIAGNOSIS AND REPAIR WORKFLOW
 Malfunctions are declared as either present or stored (depending on whether they appeared in a certain con-
text and have disappeared since, or whether they remain present but have not been diagnosed within the
current context).
 The present or stored status of malfunctions should be taken into consideration when the diagnostic tool is
used following the + after ignition supply being switched on (without acting on the system components).
 For a present malfunction, apply the procedure described in the Interpretation of malfunction section.
 For a stored malfunction, note the malfunctions displayed and apply the instructions in the Notes section.
 If the malfunction is confirmed when the instructions in the Notes section are applied, the malfunction is
present. Deal with the malfunction
 If the malfunction is not confirmed, check:
- the electrical lines which correspond to the malfunction,
- the connectors for these lines (for oxidation, bent pins, etc),
- the condition of the wires (insulation has melted or been cut, abrasions),
- the resistance of the component detected as malfunction.
Conformity Check
 The aim of the conformity check is to check data that does not produce a malfunction on the diagnostic tool
because the data is inconsistent. Therefore, this phase is used to:
- carry out malfunction finding on malfunctions that do not have a malfunction display, and which may corre-
spond to a customer complaint.
- check that the system is operating correctly and that there is no risk of a malfunction recurring after repairs.
 This section gives the malfunction finding procedures for statuses and parameters and the conditions for
checking them.
 If a status is not behaving normally or a parameter is outside the permitted tolerance values, consult the cor-
responding malfunction finding page.
Customer Complaints - Malfunction finding chart
If the test with the diagnostic tool is OK but the customer complaint is still present, the malfunction should be
processed by customer complaint.
NOTE:
A synopsis of the general procedure to follow is provided on the preceding page in the form of a flow
chart.
Malfunction Finding Procedure (Wiring Check)
Diagnostics malfunctions
Removing the connectors and/or handling the wirings may temporarily remove the origin of a DTC. The mea-
surements of the electrical voltages, resistance and insulation are generally correct, especially when the DTC
is not present at the time of the analysis (stored DTC).
Visual Check
Look for impacts under the bonnet and in the passenger compartment.
Perform a careful check of the protections, insulation and correct running of wirings.
Look for traces of oxidation.
Tactile Check
While manipulating the wirings, use the diagnostic tool to detect a change in DTC status from “stored” to
“present”.
Ensure that the connectors are correctly engaged.
Apply light stresses to the connectors.
Gently manipulate the wiring harness.
If a change of status occurs, try to isolate the origin of the incident.
Inspection of each component
Disconnect the connectors and check the appearance of the clips and blades and their crimping (no crimping
on the insulating part).
Check that the clips and blades are properly engaged in the receptacles.
Ensure that there is no rebounding of clips or blades at the time of connection.
Check the contact pressure of the clips using a suitable model blade.
Resistance Control
Test the continuity of the lines in their entirety, then section by section.
Try to create a short-circuit to earth, on the + 12 V or with another wire.
If a DTC is detected, repair or replace the wiring.
REMINDERS
Trouble Diagnosis:

DIAGNOSIS AND REPAIR WORKFLOW
EC-1041
< BASIC INSPECTION >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
There are present DTCs and stored DTCs (which appeared in a certain context and have since disappeared
or which are still present but have not had trouble diagnosis performed on them in the current context).
The “present” or “stored” status of DTCs must be considered when activating the diagnostic tool after power is
supplied to the ECM (without activating the system components).
Deal with present DTCs according to the procedure specified in the corresponding DTC trouble diagnosis.
For stored DTCs, note the DTCs displayed and follow the instructions in the Notes section.
If the DTC is confirmed when the instructions in the Notes section are applied, the malfunction is present. Deal
with the DTC.
If the DTC is not confirmed, check: Electrical lines which correspond to the malfunction
 Connectors for these lines (for oxidation, bent pins, etc.)
 Resistance of the malfunction component
 Condition of the wires (melted or cut insulation, wear)
Conformity Check
The conformity check is designed to check the states and data monitor items which do not display any DTCs
on the diagnostic tool when inconsistent. This phase therefore allows:
 Diagnoses malfunctions that do not have a DTC display, and which may correspond to a customer com-
plaint.
 Checks that the system is operating correctly and that there is no risk of a DTC reappearing after repairs.
This section gives the trouble diagnosis procedures for states and parameters and the conditions for checking
them.
If a state is not operating normally or a data monitor value is outside permitted tolerance values, you should
consult the corresponding trouble diagnosis page.
Customer Complaints - Trouble Diagnosis
If the test with the CONSULT-III is OK, but the customer complaint still present, the malfunction should be
treated by customer complaints.
SAFETY ADVICE
 The safety instructions must be followed at all times when working on components, to avoid damage or
injury:
- make sure that the battery is properly charged to avoid damaging the computers with a low load,
- use the appropriate tools,
- do not touch the xenon bulbs.
Diagnostic Work SheetINFOID:0000000001162513
DESCRIPTION
There are many operating conditions that lead to the malfunction of
engine components. A good grasp of such conditions can make trou-
bleshooting faster and more accurate.
In general, each customer feels differently about a incident. It is
important to fully understand the symptoms or conditions for a cus-
tomer complaint.
Utilize a diagnostic worksheet like the one on the next page in order
to organize all the information for troubleshooting.
Some conditions may cause the MI to come on steady or blink and
DTC to be detected. Examples:
 Vehicle ran out of fuel, which caused the engine to misfire.
 Fuel filler cap was left off or incorrectly screwed on, allowing fuel to
evaporate into the atmosphere.A synopsis of the general procedure to follow is pro-
vided on the previous page in the form of a flow
chart.
SEF907L
