NISSAN TEANA 2008 Service Manual

DIAGNOSIS SYSTEM (BCM)
DLK-45
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
ACTIVE TEST
CLUCH SWNOTE:
This item is displayed, but cannot be monitored.
BRAKE SW 1 Indicates [ON/OFF] condition of brake switch.
DETE/CANCL SW Indicates [ON/OFF] condition of the P position.
SFT PN/N SW Indicates [ON/OFF] condition of the P or N position.
S/L -LOCK Indicates [ON/OFF] condition of steering lock unit (LOCK).
S/L -UNLOCK Indicates [ON/OFF] condition of steering lock unit (UNLOCK).
S/L RELAY -F/B Indicates [ON/OFF] condition of steering lock relay.
UNLK SEN -DR Indicates [ON/OFF] condition of driver door UNLOCK status.
PUSH SW -IPDM Indicates [ON/OFF] condition of push-button ignition switch.
IGN RLY1 -F/B Indicates [ON/OFF] condition of ignition relay 1.
DETE SW -IPDM Indicates [ON/OFF] condition of the P position.
SFT PN -IPDM Indicates [ON/OFF] condition of the P or N position.
SFT P -MET Indicates [ON/OFF] condition of the P position.
SFT N -MET Indicates [ON/OFF] condition of the N position.
ENGINE STATE Indicates [STOP/STALL/CRANK/RUN] condition of engine states.
S/L LOCK-IPDM Indicates [ON/OFF] condition of steering lock unit (LOCK).
S/L UNLK-IPDM Indicates [ON/OFF] condition of steering lock unit (UNLOCK).
S/L RELAY-REQ Indicates [ON/OFF] condition of steering lock relay.
VEH SPEED 1 Displays the vehicle speed signal received from combination meter by numerical value [Km/h].
VEH SPEED 2 Displays the vehicle speed signal received from ABS, VDC or CVT by numerical value [Km/h].
DOOR STAT-DR Indicates [LOCK/READY/UNLK] condition of driver side door status.
DOOR STAT-AS Indicates [LOCK/READY/UNLK] condition of passenger side door status.
ID OK FLAG Indicates [SET/RESET] condition of key ID.
PRMT ENG STRT Indicates [SET/RESET] condition of engine start possibility.
PRMT RKE STRTNOTE:
This item is displayed, but cannot be monitored.
KEY SW -SLOT Indicates [ON/OFF] condition of key slot.
TRNK/HAT MNTR Indicates [ON/OFF] condition of trunk lid.
RKE-LOCK Indicates [ON/OFF] condition of LOCK signal from Intelligent Key.
RKE-UNLOCK Indicates [ON/OFF] condition of UNLOCK signal from Intelligent Key.
RKE-TR/BD Indicates [ON/OFF] condition of TRUNK OPEN signal from Intelligent Key.
RKE-PANICNOTE:
This item is displayed, but cannot be monitored.
RKE-P/W OPENNOTE:
This item is displayed, but cannot be monitored.
RKE-MODE CHG Indicates [ON/OFF] condition of MODE CHANGE signal from Intelligent Key.
RKE OPE COUN1When remote keyless entry receiver receives the signal transmitted while operating on Intelligent Key, the
numerical values start changing.
RKE OPE COUN2NOTE:
This item is displayed, but cannot be monitored. Monitor Item Condition

DLK-46
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
TRUNK
TRUNK : CONSULT-III Function (BCM - TRUNK)INFOID:0000000003794767
BCM CONSULT-III FUNCTION
CONSULT-III performs the following functions via CAN communication with BCM.
Te s t i t e m D e s c r i p t i o n
BATTERY SAVERThis test is able to check interior room lamp operation.
The interior room lamp will be activated when “ON” on CONSULT-III screen is touched.
PW REMOTO DOWN SETNOTE:
This item is displayed, but cannot be used.
OUTSIDE BUZZERThis test is able to check Intelligent Key warning buzzer operation.
The Intelligent Key warning buzzer will be activated when “ON” on CONSULT-III screen is touched.
INSIDE BUZZERThis test is able to check warning chime in combination meter operation.
 Take away warning chime sounds when “TAKE OUT” on CONSULT-III screen is touched.
 Key warning chime sounds when “KEY” on CONSULT-III screen is touched.
 P position warning chime sounds when “KNOB” on CONSULT-III screen is touched.
INDICATORThis test is able to check warning lamp operation.
 “KEY” Warning lamp illuminates when “RED ON” on CONSULT-III screen is touched.
 “KEY” Warning lamp blinks when “RED IND” on CONSULT-III screen is touched.
INT LAMPThis test is able to check interior room lamp operation.
The interior room lamp will be activated when “ON” on CONSULT-III screen is touched.
LCDThis test is able to check meter display information
 Engine start information displays when “BP N” on CONSULT-III screen is touched.
 Engine start information displays when “BP I” on CONSULT-III screen is touched.
 Key ID warning displays when “ID NG” on CONSULT-III screen is touched.
 Steering lock information displays when “ROTAT” on CONSULT-III screen is touched.
 P position warning displays when “SFT P” on CONSULT-III screen is touched.
 Intelligent Key insert information displays when “INSRT” on CONSULT-III screen is touched.
 Intelligent Key low battery warning displays when “BATT” on CONSULT-III screen is touched.
 Take away warning displays when “OUTKEY” on CONSULT-III screen is touched.
 OFF position warning displays when “LK WN” on CONSULT-III screen is touched.
TRUNK/GLASS HATCHThis test is able to check trunk lid opener actuator open operation.
This actuator opens when “OPEN” on CONSULT-III screen is touched.
FLASHERThis test is able to check security hazard lamp operation.
The hazard lamps will be activated when “RH” or “LH”on CONSULT-III screen is touched.
HORNThis test is able to check horn operation.
The horn will be activated when “ON” on CONSULT-III screen is touched.
P RANGEThis test is able to check control device power supply
Control device power is supplied when “ON” on CONSULT-III screen is touched.
ENGINE SW ILLUMIThis test is able to check push-ignition switch illumination operation.
Push-ignition switch illumination illuminates when “ON” on CONSULT-III screen is touched.
LOCK INDICATORThis test is able to check LOCK indicator in push-ignition switch operation.
LOCK indicator in push-ignition switch illuminates when “ON” on CONSULT-III screen is touched.
ACC INDICATORThis test is able to check ACC indicator in push-ignition switch operation.
ACC indicator in push-ignition switch illuminates when “ON” on CONSULT-III screen is touched.
IGNITION ON INDThis test is able to check ON indicator in push-ignition switch operation.
ON indicator in push-ignition switch illuminates when “ON” on CONSULT-III screen is touched.
KEY SLOT ILLUMIThis test is able to check key slot illumination operation.
Key slot illumination illuminates when “ON” on CONSULT-III screen is touched.
TRUNK/BACK DOORThis test is able to check trunk lid opener actuator open operation.
This actuator opens when “OPEN” on CONSULT-III screen is touched.

DIAGNOSIS SYSTEM (BCM)
DLK-47
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DATA MONITOR
ACTIVE TEST
Diagnosis mode Function Description
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
Monitor Item Contents
PUSH SW Indicates [ON/OFF] condition of push-button ignition switch.
UNLK SEN -DRNOTE:
This item is displayed, but cannot be monitored.
VEH SPEED 1 Indicates [km/h] condition of vehicle speed signal from combination meter.
KEY CYL SW-TRNOTE:
This item is displayed, but cannot be monitored.
TR CANCEL SWNOTE:
This item is displayed, but cannot be monitored.
TR/BD OPEN SW Indicates [ON/OFF] condition of trunk lid opener switch.
TRNK/HAT MNTRNOTE:
This item is displayed, but cannot be monitored.
RKE-TR/BDNOTE:
This item is displayed, but cannot be monitored.
Test item Description
TRUNK/GLASS HATCH This test is able to check trunk lid opener actuator open operation.

DLK-48
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
U1000 CAN COMM CIRCUIT
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
BCM
BCM : DescriptionINFOID:0000000003794769
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detectability. Modern vehi-
cles are equipped with many electronic control units, and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN H-line, CAN L-line) allowing a high rate of information transmission with less
wiring. Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart. Refer to LAN-22, "
CAN Communication Signal Chart".
BCM : DTC LogicINFOID:0000000003794770
DTC DETECTION LOGIC
BCM : Diagnosis ProcedureINFOID:0000000003794771
1.PERFORM SELF DIAGNOSTIC
1. Turn ignition switch ON and wait for 3 seconds or more.
2. Check “Self Diagnostic Result”.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Refer to LAN-14, "Trouble Diagnosis Flow Chart".
NO >> Refer to GI-35, "
Intermittent Incident".
DTC
No.Trouble diagnosis
nameDTC detecting condition Possible cause
U1000 CAN COMM CIRCUITWhen BCM cannot communicate CAN com-
munication signal continuously for 2 seconds
or more.CAN communication system

U1010 CONTROL UNIT (CAN)
DLK-49
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
U1010 CONTROL UNIT (CAN)
BCM
BCM : DTC LogicINFOID:0000000003794775
DTC DETECTION LOGIC
BCM : Diagnosis ProcedureINFOID:0000000003794776
1.REPLACE BCM
When DTC [U1010] is detected, replace BCM.
>> Replace BCM. Refer to BCS-78, "
Removal and Installation"
BCM : Special Repair RequirementINFOID:0000000003794777
1.REQUIRED WORK WHEN REPLACING BCM
Initialize control unit. Refer to CONSULT-III operation manual NATS-IVIS/NVIS.
>> Work end.
DTC
No.Trouble diagnosis name DTC detecting condition Possible cause
U1010 CONTROL UNIT (CAN) BCM detected internal CAN communication circuit malfunction. BCM

DLK-50
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2621 INSIDE KEY ANTENNA 1
B2621 INSIDE KEY ANTENNA 1
DescriptionINFOID:0000000003794823
Detects whether Intelligent Key is inside the vehicle.
Installed in the instrument center.
DTC LogicINFOID:0000000003794824
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Perform inside key antenna (“INSIDE ANT DIAGNOSIS”) on Work Support” in “INTELLIGENT KEY”.
2. Perform “INTELLIGENT KEY” Self Diagnostic Result.
Is inside key antenna DTC detected?
YES >> Refer to DLK-50, "Diagnosis Procedure".
NO >> Inside key antenna (instrument center) is OK.
Diagnosis ProcedureINFOID:0000000003794825
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL 1
1. Turn ignition switch OFF.
2. Check signal between BCM harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK INSIDE KEY ANTENNA CIRCUIT
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2621INSIDE ANTENNA 1
CIRCUITAn excessive high or low voltage from inside anten-
na is sent to BCM. Inside key antenna (instrument
center)
 Between BCM and Inside key an-
tenna (instrument center)
(+)
(–) ConditionSignal
(Reference value.) BCM
Connector Terminal
M122 78, 79 GroundPlace Intelligent Key inside the vehi-
cle.
Place Intelligent Key outside the ve-
hicle.
JMKIA0062GB
JMKIA0063GB

B2621 INSIDE KEY ANTENNA 1
DLK-51
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
1. Disconnect BCM and inside key antenna connector (instrument center).
2. Check continuity between BCM harness connector and inside key antenna (instrument center) harness
connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK INSIDE KEY ANTENNA INPUT SIGNAL 2
1. Replace inside key antenna (instrument center). (New antenna or other antenna)
2. Connect BCM and inside key antenna (instrument center) connector.
3. Check signal between BCM harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace inside key antenna (instrument center). Refer to DLK-235, "INSTRUMENT CENTER :
Removal and Installation".
NO >> Replace BCM. Refer to BCS-78, "
Removal and Installation".
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
BCM Inside key antenna (instrument center)
Continuity
Connector Terminal Connector Terminal
M12278
M1052
Existed
79 1
BCM
GroundContinuity
Connector Terminal
M12278
Not existed
79
(+)
(–) ConditionSignal
(Reference value.) BCM
Connector Terminal
M122 78, 79 GroundPlace Intelligent Key inside the vehi-
cle.
Place Intelligent Key outside the ve-
hicle.
JMKIA0062GB
JMKIA0063GB

DLK-52
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2622 INSIDE KEY ANTENNA 2
B2622 INSIDE KEY ANTENNA 2
DescriptionINFOID:0000000003794826
Detects whether Intelligent Key is inside the vehicle.
Installed in the console.
DTC LogicINFOID:0000000003794827
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Perform inside key antenna (“INSIDE ANT DIAGNOSIS”) on “Work Support” in “INTELLIGENT KEY”.
2. Perform “INTELLIGENT KEY” Self Diagnostic Result.
Is inside key antenna DTC detected?
YES >> Refer to DLK-52, "Diagnosis Procedure".
NO >> Inside key antenna (console) is OK.
Diagnosis ProcedureINFOID:0000000003794828
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL 1
1. Turn ignition switch OFF.
2. Check signal between BCM harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK INSIDE KEY ANTENNA CIRCUIT
1. Disconnect BCM and inside key antenna (console) connector.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2622INSIDE ANTENNA 2
CIRCUITAn excessive high or low voltage from inside anten-
na is sent to BCM. Inside key antenna (console)
 Between BCM and Inside key an-
tenna (console)
(+)
(–) ConditionSignal
(Reference value.) BCM
Connector Terminal
M122 72, 73 GroundPlace Intelligent Key inside the vehi-
cle.
Place Intelligent Key outside the vehi-
cle.
JMKIA0062GB
JMKIA0063GB

B2622 INSIDE KEY ANTENNA 2
DLK-53
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between BCM harness connector and inside key antenna (console) harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK INSIDE KEY ANTENNA INPUT SIGNAL 2
1. Replace inside key antenna (console). (New antenna or other antenna)
2. Connect BCM and inside key antenna (console) connector.
3. Check signal between BCM harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace inside key antenna (console). Refer to DLK-236, "CONSOLE : Removal and Installation".
NO >> Replace BCM. Refer to BCS-78, "
Removal and Installation".
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
BCM Inside key antenna (console)
Continuity
Connector Terminal Connector Terminal
M12272
M2622
Existed
73 1
BCM
GroundContinuity
Connector Terminal
M12272
Not existed
73
(+)
(–) ConditionSignal
(Reference value.) BCM
Connector Terminal
M122 72, 73 GroundPlace Intelligent Key inside the vehi-
cle.
Place Intelligent Key outside the vehi-
cle.
JMKIA0062GB
JMKIA0063GB

DLK-54
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2623 INSIDE KEY ANTENNA 3
B2623 INSIDE KEY ANTENNA 3
DescriptionINFOID:0000000003794829
Detects whether Intelligent Key is inside the vehicle.
Installed in the trunk room.
DTC LogicINFOID:0000000003794830
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Perform inside key antenna (“INSIDE ANT DIAGNOSIS”) on “Work Support” in “INTELLIGENT KEY”.
2. Perform “INTELLIGENT KEY” Self Diagnostic Result.
Is inside key antenna DTC detected?
YES >> Refer to DLK-54, "Diagnosis Procedure".
NO >> Inside key antenna (trunk room) is OK.
Diagnosis ProcedureINFOID:0000000003794831
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL 1
1. Turn ignition switch OFF.
2. Check signal between BCM harness connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK INSIDE KEY ANTENNA CIRCUIT
1. Disconnect BCM and inside key antenna (trunk room) connector.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2623INSIDE ANTENNA 3
CIRCUITAn excessive high or low voltage from inside anten-
na is sent to BCM. Inside key antenna (trunk room)
 Between BCM and Inside key an-
tenna (trunk room)
(+)
(–) ConditionSignal
(Reference value.) BCM
Connector Terminal
M121 34, 35 GroundPlace Intelligent Key inside the vehi-
cle.
Place Intelligent Key outside the ve-
hicle.
JMKIA0062GB
JMKIA0063GB
