U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DTC LogicINFOID:0000000003809617
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000003809618
1.REPLACE BCM
When DTC “U1010: CONTROL UNIT (CAN)” is detected, replace BCM.
>> Replace BCM. Refer to BCS-78, "
Exploded View".
DTCCONSULT-III display de-
scriptionDTC Detection Condition Possible cause
U1010 CONTROL UNIT (CAN) BCM detected internal CAN communication circuit malfunction. BCM

BCS
U0415 VEHICLE SPEED SIG
BCS-35
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L B A
O
P N
U0415 VEHICLE SPEED SIG
DescriptionINFOID:0000000003809619
U0415 is displayed if any unusual condition is present in the reception status of the vehicle speed signal from
the ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000003809620
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION
1. Erase the DTC.
2. Turn ignition switch OFF.
3. Perform the “Self Diagnostic Result” of CONSULT-III, when passed 2 seconds or more after the ignition
switch is turned ON.
Is any DTC detected?
YES >> Refer to BCS-35, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003809621
1.ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAG RESULTS
Perform “Self-Diagnostic Result” of ABS actuator and electric unit (control unit) with CONSULT-III. Refer to
BRC-13, "
CONSULT-III Function" (ABS) or BRC-80, "CONSULT-III Function" (VDC/TCS/ABS).
Is any DTC detected?
YES >> Repair or replace the malfunctioning part.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
DTC CONSULT-III display
descriptionDTC Detection Condition Probable cause
U0415 VEHICLE SPEED SIGWhen the vehicle speed signal received from
the ABS actuator and electric unit (control
unit) remains abnormal for 2 seconds or more. ABS actuator and electric unit (control unit)
BCM

BCS-36
< COMPONENT DIAGNOSIS >
B2562 LOW VOLTAGE
B2562 LOW VOLTAGE
DTC LogicINFOID:0000000003809622
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION
1. Erase DTC.
2. Turn ignition switch OFF.
3. Perform the “Self Diagnostic Result” of CONSULT-III, when passed 1.5 seconds or more after the ignition
switch is turned ON.
Is any DTC detected?
YES >> Refer to BCS-36, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003809623
1.CHECK POWER SUPPLY CIRCUIT
Check BCM power supply circuit. Refer to BCS-37, "
Diagnosis Procedure".
Is the circuit normal?
YES >> Replace BCM. Refer to BCS-78, "Exploded View".
NO >> Repair the malfunctioning part.
DTCCONSULT-III display
descriptionDTC Detection Condition Possible cause
B2562 LOW VOLTAGEWhen the power supply voltage to BCM remains less
than 8.8 V for 1.5 seconds or moreHarness or connector (power supply
circuit)

BCS
POWER SUPPLY AND GROUND CIRCUIT
BCS-37
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L B A
O
P N
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000003809624
1.CHECK FUSE AND FUSIBLE LINK
Check that the following fuse and fusible link are not blown.
Is the fuse fusing?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is
blown.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check voltage between BCM harness connector and ground.
Is the measurement value normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Does continuity exist?
YES >> INSPECTION END
NO >> Repair harness or connector.
Signal name Fuse and fusible link No.
Battery power supplyI
10
Te r m i n a l s
Vo l ta g e
(Approx.) (+) (−)
BCM
Ground Connector Terminal
M118 1
Battery voltage
M119 11
BCM
GroundContinuity
Connector Terminal
M119 13 Existed

BCS-38
< COMPONENT DIAGNOSIS >
COMBINATION SWITCH INPUT CIRCUIT
COMBINATION SWITCH INPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000003809625
1.CHECK INPUT 1 - 5 SYSTEM CIRCUIT FOR OPEN
1. Turn the ignition switch OFF.
2. Disconnect the BCM and combination switch connectors.
3. Check continuity between BCM harness connector and combination switch harness connector.
Does continuity exist?
YES >> GO TO 2.
NO >> Repair the harnesses or connectors.
2.CHECK INPUT 1 - 5 SYSTEM CIRCUIT FOR SHORT
Check for continuity between BCM harness connector and ground.
Does continuity exist?
YES >> Repair the harnesses or connectors.
NO >> GO TO 3.
3.CHECK BCM OUTPUT VOLTAGE
1. Connect the BCM connector.
2. Check voltage between BCM harness connector and ground.
Is the measurement value normal?
YES >> GO TO 4.
NO >> Replace BCM. Refer to BCS-78, "
Exploded View".
SystemBCM Combination switch
Continuity
Connector Terminal Connector Terminal
INPUT 1
M122107
M10311
Existed INPUT 2 109 9
INPUT 3 88 7
INPUT 4 108 10
INPUT 5 87 13
SystemBCM
GroundContinuity
Connector Terminal
INPUT 1
M122107
Not existed INPUT 2 109
INPUT 3 88
INPUT 4 108
INPUT 5 87
SystemTe r m i n a l s
Vo l ta g e
(Approx.) (+) (−)
BCM
Ground Connector Terminal
INPUT 1
M122107
Refer to BCS-
42, "Refer-
ence Value". INPUT 2 109
INPUT 3 88
INPUT 4 108
INPUT 5 87

BCS
COMBINATION SWITCH INPUT CIRCUIT
BCS-39
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L B A
O
P N
4.CHECK BCM INPUT SIGNAL
1. Connect the combination switch connector.
2. Turn ON any switch in the system that is malfunctioning.
3. Check voltage between BCM harness connector and ground.
Is the measurement value normal when any of the switches is turned ON?
YES >> Replace BCM. Refer to BCS-78, "Exploded View"
NO >> Replace the combination switch.
SystemTe r m i n a l s
Voltag e
(Approx.) (+) (−)
BCM
Ground Connector Terminal
INPUT 1
M122107
Refer to BCS-
42, "Refer-
ence Value". INPUT 2 109
INPUT 3 88
INPUT 4 108
INPUT 5 87

BCS-40
< COMPONENT DIAGNOSIS >
COMBINATION SWITCH OUTPUT CIRCUIT
COMBINATION SWITCH OUTPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000003809626
1.CHECK OUTPUT 1 - 5 SYSTEM CIRCUIT FOR OPEN
1. Turn the ignition switch OFF.
2. Disconnect the BCM and combination switch connectors.
NOTE:
BCM connector disconnects M123 only.
3. Check continuity between BCM harness connector and combination switch harness connector.
Does continuity exist?
YES >> GO TO 2.
NO >> Repair the harnesses or connectors.
2.CHECK OUTPUT 1 - 5 SYSTEM CIRCUIT FOR SHORT
Check for continuity between BCM harness connector and ground.
Does continuity exist?
YES >> Repair the harnesses or connectors.
NO >> GO TO 3.
3.CHECK COMBINATION SWITCH INTERNAL CIRCUIT
1. Connect the combination switch connector.
2. Turn ON any switch in the system that is malfunctioning.
3. Check voltage between combination switch harness connector and ground.
NOTE:
Check that the combination switch outputs a signal from combination switch input system.
SystemBCM Combination switch
Continuity
Connector Terminal Connector Terminal
OUTPUT 1
M123143
M10312
Existed OUTPUT 2 144 14
OUTPUT 3 145 5
OUTPUT 4 146 2
OUTPUT 5 142 8
SystemBCM
GroundContinuity
Connector Terminal
OUTPUT 1
M123143
Not existed OUTPUT 2 144
OUTPUT 3 145
OUTPUT 4 146
OUTPUT 5 142

BCS
COMBINATION SWITCH OUTPUT CIRCUIT
BCS-41
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L B A
O
P N
Is the measurement value normal when any of the switches is turned ON?
YES >> Replace BCM. Refer to BCS-78, "Exploded View"
NO >> Replace the combination switch.
SystemTe r m i n a l s
Value (Approx.) (+) (−)
Combination switch
Ground Connector Terminal
OUTPUT 1
M10312
1.4 V OUTPUT 2 14
OUTPUT 3 5
OUTPUT 4 2
OUTPUT 5 8
JPMIA0041GB

BCS-42
< ECU DIAGNOSIS >
BCM (BODY CONTROL MODULE)
ECU DIAGNOSIS
BCM (BODY CONTROL MODULE)
Reference ValueINFOID:0000000003809627
VALUES ON THE DIAGNOSIS TOOL
CONSULT-III MONITOR ITEM
Monitor Item Condition Value/Status
FR WIPER HIOther than front wiper switch HI Off
Front wiper switch HI On
FR WIPER LOWOther than front wiper switch LO Off
Front wiper switch LO On
FR WASHER SWFront washer switch OFF Off
Front washer switch ON On
FR WIPER INTOther than front wiper switch INT Off
Front wiper switch INT On
FR WIPER STOPFront wiper is not in STOP position Off
Front wiper is in STOP position On
INT VOLUME Wiper intermittent dial is in a dial position 1 - 7 Wiper intermittent dial position
TURN SIGNAL ROther than turn signal switch RH Off
Turn signal switch RH On
TURN SIGNAL LOther than turn signal switch LH Off
Turn signal switch LH On
TAIL LAMP SWOther than lighting switch 1ST and 2ND Off
Lighting switch 1ST or 2ND On
HI BEAM SWOther than lighting switch HI Off
Lighting switch HI On
HEAD LAMP SW 1Other than lighting switch 2ND Off
Lighting switch 2ND On
HEAD LAMP SW 2Other than lighting switch 2ND Off
Lighting switch 2ND On
PASSING SWOther than lighting switch PASS Off
Lighting switch PASS On
AUTO LIGHT SWOther than lighting switch AUTO Off
Lighting switch AUTO On
FR FOG SWFront fog lamp switch OFF Off
Front fog lamp switch ON On
RR FOG SWRear fog lamp switch OFF Off
Rear fog lamp switch ON On
DOOR SW-DRDriver door closed Off
Driver door opened On
DOOR SW-ASPassenger door closed Off
Passenger door opened On
DOOR SW-RRRear RH door closed Off
Rear RH door opened On

BCS
BCM (BODY CONTROL MODULE)
BCS-43
< ECU DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L B A
O
P N
DOOR SW-RLRear LH door closed Off
Rear LH door opened On
DOOR SW-BKNOTE:
The item is indicated, but not monitored. Off
CDL LOCK SWOther than power door lock switch LOCK Off
Power door lock switch LOCK On
CDL UNLOCK SWOther than power door lock switch UNLOCK Off
Power door lock switch UNLOCK On
KEY CYL LK-SWNOTE:
The item is indicated, but not monitored. Off
KEY CYL UN-SWNOTE:
The item is indicated, but not monitored. Off
KEY CYL SW-TRNOTE:
The item is indicated, but not monitored. Off
HAZARD SWHazard switch is OFF Off
Hazard switch is ON On
REAR DEF SW
NOTE:
At model with BOSE au-
dio system this item is in-
dicated, but is not
monitored.Rear window defogger switch is OFF Off
Rear window defogger switch is ON On
TR CANCEL SWNOTE:
The item is indicated, but not monitored. Off
TR/BD OPEN SWTrunk lid opener switch OFF Off
While the trunk lid opener switch is turned ON On
TRNK/HAT MNTRTrunk lid closed Off
Trunk lid opened On
RKE-LOCKLOCK button of the key is not pressed Off
LOCK button of the key is pressed On
RKE-UNLOCKUNLOCK button of the key is not pressed Off
UNLOCK button of the key is pressed On
RKE-TR/BDTRUNK OPEN button of the key is not pressed Off
TRUNK OPEN button of the key is pressed On
RKE-PANICNOTE:
The item is indicated, but not monitored. Off
RKE-P/W OPENNOTE:
The item is indicated, but not monitored. Off
RKE-MODE CHGLOCK/UNLOCK button of the key is not pressed and held simulta-
neouslyOff
LOCK/UNLOCK button of the key is pressed and held simulta-
neouslyOn
OPTICAL SENSORBright outside of the vehicle Close to 5 V
Dark outside of the vehicle Close to 0 V
REQ SW -DRDriver door request switch is not pressed Off
Driver door request switch is pressed On
REQ SW -ASPassenger door request switch is not pressed Off
Passenger door request switch is pressed On Monitor Item Condition Value/Status
