AUTOMATIC TRANSAXLE - Rear Clutch Assemblv 21-307REAR CLUTCH ASSEMBLY
,A-DISASSEMBLY AND REASSEMBLY
--.TFAO 606
Disassembly steps
1.Seal ringl 2. Input shaft
3.O-ring4.Snap ring5.Thrust race
6.Seal ringl + 7. Snap ringI)+ 8. Clutch reaction plate9.Clutch disc
l + 10. Clutch plate
11.Wave spring9
.TFA0265
** *4 12. Snap ring13.Returnspring
14. Rear clutch piston
15.D-ring16.D-ring17. Rear clutch retainerNOTE
(1) Reverse the disassembly procedures to reassemble.(2) +e : Refer to “Service Points of Disassembly”.(3) l + : Refer to “Service Points of Reassembly”.(4) 0 : Non-reusable parts

21-308 AUTOMATIC TRANSAXLE - Rear Clutch Assembly
@
/
(
TFAO240SERVICE POINTS OF
DISASSEM.BLY12. REMOVAL OF SNAP RING
(1) Using the special tool, compress the
returns spring.
(2) Using the snap ring pliers, remove the snap ring.
SERVICE POINTS OF REASSEMBLY12. INSTALLATION OF SNAP RING
(1) Using the special tool, compress the return spring.
(2) Using the snap ring pliers, install the snap ring.
10. INSTALLATION OF CLUTCH PLATE/*. CLUTCH REAC-
TION PLATE
Assemble the clutch plate and reaction plate, arranging
them by the missing tooth [See figure
@I.
NOTEThis is so the automatic transmission fluid escapes easily
and there is good cooling of the plate and disc.
7. SELECTION OF SNAP RING
Check clearance between the snap ring and clutch reaction
plate. To check the clearance, hold entire circumference ofthe clutch reaction plate down with 50
N (11 Ibs.) force. If
clearance is out of standard value, select a snap ring to
obtain the standard value.
Standard value:
1.0-1.2 mm (.034-.047 in.)
2. INSTALLATION OF INPUT SHAFT
Align the input shaft oil groove and rear clutch retainer
matching mark and assemble.

.-
AUTOMATIC TRANSAXLE - End Clutch Assembly21-309END CLUTCH ASSEMBLY
NZIIJWD
F4A2233
DISASSEMBLY AND REASSEMBLYNo. of clutch discs and plates
Disassembly steps
1.Seal ring
l * 2. Snap ring3. Clutch reaction plate
4.Clutch disc5.Clutch platel + 6. Snap ring7.Washer8.Return spring9. End clutch piston
10.Oil seal11.D-ring12. End clutch retainer13.Oil seal
9
TFA0607
5TFA0608
NOTE(1) Reverse the disassembly procedures to reassemble.(2) l e : Refer to “Service Points of Disassembly”.(3) ++ : Refer to “Service Points of Reassembly”.(4) q : Non-reusable parts
SERVICE POINTS OF REASSEMBLY6. INSTALLATION OF SNAP RING
Using the special tool, install the snap ring.
Caution
Check that the snap ring is seated firmly in the groove.

AUTOMATIC TRANSAXLE - End Clutch Assembly
TFA02682. SELECTION OF SNAP RING
First install the snap ring and then check if the gap between
the snap ring and clutch reaction plate reaches the standardvalue. When measuring the gap, press the circumference
,“i
of the clutch reaction plate firmly with a force of 50 Nm (11
Ibs.). If the gap is outside the standard value, select a snap
ring and adjust until it reaches the standard value.
Standard value:
0.4-0.65 mm (.016-.026 in.)
0.6-0.85 mm (.024-.033 in.)

AUTOMATIC TRANSAXLE - Planetary Gear 21-311
PLANETARY GEAR

-. DISASSEMBLY AND REASSEMBLY
35-45 Nm26-32 ft.lbs.
NOTE(I) Reverse the disassembly procedures to reass$mble.(2) *I) : Refer to ::Servjce Points of Disassembly,Ii/+ : Refer to Service Points of Reassembly .b: Non-reusable parts
NZlLKAJ
,. /.
ep4”
I9
TFAOS22
8
Disassembly stepsI. Bolt
2.Lock plate3. One-way clutch outer race
4.End plate
1)45.One-way clutch6.End plate7.Pinion shaft8. Front thrust washer9.Spacer bushing10. Short pinion
Il. Roller+e
l + 12. Thrust bearing13.Planet carrier
i
SERVICE POINTS OF DISASSEMBLY12. REMOVAL OF THRUST BEARING
(1) Remove the only one short pinion. Use care not to drop
and lose the 17 rollers in the short pinion. Do not
remove the other short pinions.
(2) Remove the thrust bearing.

21-312AUTOMATIC TRANSAXLE - Planetary Gear
SERVICE POINTS OF REASSEMBLY12. INSTALLATlON OF THRUST BEARING
%(1) Install a thrust bearing on the carrier. Make sure that it
c,ifits correctly in the spot faced portion of the carrier.
(2) Apply
Vaseline unsparingly to the inside surface of the
short pinion and attach the 17 rollers on the surface.
(3) Line up the holes of the rear thrust washer and front
thrust washer “A” with the shaft hole of the carrier.
(4) Install the short pinion, spacer bushing and front thrust
washer and align the holes. Use care not to allow the
rollers to get out of position.
r?
.*-d’
(5) Insert the pinion shaft. Make sure that the flattened endof pinion shaft is correctly fitted in the hole of the rear
thrust plate when the pinion shafts is inserted.
5. INSTALLATION OF ONE-WAY CLUTCH
Push the one-way clutch into the outer race. Make sure
that arrow on the outside circumference of cage is directedupward as shown in the illustration when the one-way
clutch is pushed in.
J-+
-il

AUTOMATIC TRANSAXLE - Planetary Gear 21-313PLANETARY GEAR
-- DISASSEMBLY AND REASSEMBLY
s
NOTF
Disassembly steps
1. Thrust bearing
4*+4 2. Rivete+ 3. Waved washer4. One-way clutch outer race- - . .
TFA0491(1) Reverse the disassembly procedures to reassemble.
(2)
+e : Refer to “Service Points of Disassembly”.
(3) l : Refer to “Service Points of Reassembly”.
(4) m : Non-reusable parts5. tnd plate
~~ 6. One-way clutch7. End plate8. Planet carrier
SERVICE POINTS OF DISASSEMBLY2. REMOVAL OF RIVET
(1) Move the stopper plate so it does not hit the rivet head.
NOTEThe catch of the stopper plate should not catch in the
one-way clutch outer race groove.
(2) Use a pin punch or similar tool and drive out the rivet.

21-314AUTOMATIC TRANSAXLE - Planetary Gear
TFM0506
SERVICE POINTS OF REASSEMBLY6. INSTALLATION OF ONE-WAY CLUTCH*b
*Press in the one-way clutch so the gauge part of the
cJ
one-way clutch is in the direction shown by the arrow in the
figure.3. INSTALLATION OF WAVED WASHER
Install so the concave (indented) part of the waved washer
is on the outer race side.
2. INSTALLATION OF RIVET
Using a punch, caulk the rivet by pressing.
NOTEUse a punch with a tip with a 60” angle.rCaulk the rivet surely with a load of 1
l,OOO-13,000 N es
(2,425-2,866 Ibs.).
‘I

AUTOMATIC TRANSAXLE - %t:i kk?& set 21-315ANNULUS GEAR AND TRANSFER DRIVE GEAR SET
NzlwE
WASSEMBLY AND REASSEMBLY
Disassembly steps
l +1. Snap ring+eM 2. Bearing
W l 3. Transfer drive gear
+er)+ 4. Bearing
5. Snap ring
6. Outbut flange7. Annulus gear
NOTE(I) Reverse the disassembly procedures to reassemble.(2) +e : Refer to “Service Points of Disassembly”.(3) H : Refer to “Service Points of Reassembly”.170178
M D998348
/
170113
MD998348
170114
MD998348
170115
SERVICE POINTS OF DISASSEMBLY2. REMOVAL OF BEARING
Using the special tool, remove the bearing from the output
flange.3. REMOVAL OF TRANSFER DRIVE GEAR
Using the special tool, remove the transfer drive gear from
the output flange.
4. REMOVAL OF BEARING
Using the special tool, remove the bearing from the output
flange.

21-316AUTOMATIC TRANSAXLEAnnulus Gear and- Transfer Drive Gear Set
SERVICE POINTS OF REASSEMBLY4. INSTALLATION OF BEARING
L:Using the special tool, install the bearing on the output
*h-
flange.MD998813
TFAO502
TFA0503
MD99881 2
MD998824
TFA03843. INSTALLATION OF TRANSFER DRIVE GEAR
Using the special tool, install the transfer drive gear in
proper direction. The direction can be identified by the
groove provided in one of the pinion side surfaces.
Caution
Replace the output flange and transfer drive gear as a
set.2. INSTALLATION OF BEARING
Using the special tool, install the bearing on the output
flange.@%1. SELECTION OF SNAP RING
Select a snap ring, which should be the thickest one that
can be installed in groove.
Standard value:
O-0.06 mm (O-.0024 in.)
